FS-2 / FS-2N
MONITOR

7. Navigation and parameter table

The push buttons
of values and acknowledgement within the parameters arranged in columns.
The parameters above
normally set only once during commissioning depending on the machines or sys-
tems to be monitored.
The parameters below these entries are application parameters. They can be set or
changed more often.
RUN
mode
selective
indication
Istwert
actual value
Eingang 1
input 1
[RPM/Hz] [RPM/Hz]
Istwert
actual value
Eingang 2
input 2
[RPM/Hz]
[RPM/Hz]
Differenz-
differential
Impulse
pulses
1 > 2
1 > 2
Differenz-
differential
Impulse
pulses
2 > 1
2 > 1
26
PAGE
/ and the push button
and
VER
DIM
OPP
SOP
FW1*
STP
NC1
CT1
FO1
SP1
DT1
FT1
are used for the navigation, entry
are general system parameters. They are
parameter range
and PRG mode
FW2*
NC2
CT2
FO2
SP2
DT2
FT2
system
parameter
back to the
RUN mode
application
parameters
*) only FS-2N
