SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
DV22V: Impact Drill
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
V
Rated voltage
P
Power Input
n
No-load speed
0
Rotation only function
Rotation and impact function
Concrete
Switching ON
Switching OFF
On / Off switch lock-on
Change rotation speed - High speed
Change rotation speed - Low speed
Clockwise rotation
Counterclockwise rotation
Disconnect mains plug from electrical outlet
Class II tool

STANDARD ACCESSORIES

In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
(1) Chuck wrench (Spec. only for keyed chuck) ................1
(2) Side handle ..................................................................1
(3) Depth gauge ................................................................1
(4) Plastic case ..................................................................1
Standard accessories are subject to change without notice.
APPLICATIONS
○ By combined actions of ROTATION and IMPACT:
Boring holes in hard materials (concrete, marble, granite,
tiles, etc.)
○ By ROTATIONAL action:
Boring holes in metal, wood and plastic.
SPECIFICATIONS
Voltage*
1
Power input
Speed range
No load speed
Steel
Capacity Concrete
Wood
Full-load impact rate
Weight*
2
*1 Be sure to check the nameplate on product as it is subject
to change by areas.
*2 Weight: According to EPTA-Procedure 01/2014
NOTE
Due to HiKOKI's continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.

MOUNTING AND OPERATION

Action
Insulated gripping surface
Fixing and removing side handle
Using depth stopper
Mounting and dismounting of
the bit
Selecting rotation direction
Selecting the operating mode
Switch operation
Locking-on the switch
Releasing the switch
Change rotation speed
Selecting accessories
Selecting the appropriate drill bit
○ When boring concrete or stone
Use the drill bits specifi ed in the Optional Accessories.
○ When boring metal or plastic
Use an ordinary metalworking drill bit.
○ When boring wood
Use ordinary woodworking drill bit.
However, when drilling 6.5 mm or smaller holes, use a
metalworking drill bit.
4
(110 V, 220 V, 230 V, 240 V)
1120 W* 1
1 2
0 – 3000 min
0 – 1100 min -1
16 mm 8 mm
22 mm 13 mm
40 mm 25 mm
22000 min
8100 min -1
3.0 kg
