6.7 Attaching the optional connecting cable for IPCA32500 and IPCA72500
Using the optional connecting cables TVAC40720 and TVAC40730, suitable dome cameras can
gain the following additional interfaces:
Suitable for
Audio input,
3.5 mm stereo
plug
Audio output,
3.5 mm stereo
plug
1 x switching
input
1 x switching
output
Video output,
BNC 1 Vss

6.8 Switching input and switching output

The maximum load values must be observed, otherwise the camera may be
damaged irreparably.
Switching input
Switching output DO+
TVAC40720
IPCA32500
√
√
√
√
√
Name Connection instructions
DI+ 5 V DC ~ 12 V DC max. 50 mA
DI-
Max. 60 V DC/AC, max. 400 mA, Ron=1.4 Ohm (photo
relay)
DO-
TVAC40730
IPCA72500
√
√
√
√
√
71
