Day:
Night:

10.4.1.5 Privacy masking

Up to three ranges can be selected in the video. The ranges are automatically named P1, P2 and
P3. These ranges are marked as black in the actual video image.
List of ranges:
Add:
Delete:
The time range set represents the day time range. Outside
of these times, night mode is used.
the camera stays in day mode permanently. In day mode the infrared
cut filter (ICR) is constantly in front of the lens. This means that the
image sensor can't pick up any infrared light.
the camera stays in night mode permanently. The infrared cut filter is
constantly separated from the lens.
list of all the ranges established
if you press this button, a new entry is created in the list. Then click on
the list entry to select a mask further on in the preview. Selecting a
second one will remove the previously selected mask. The masks are
applied by saving them to the settings.
deleting a range previously selected in the list of ranges.
