INSTALLATION, INSTRUCTIONS
7. Ensure that the two adjuster
buckle parts are sitting correct-
ly. Pass the webbing through
the slot closest to the waist
belt.
10. Pass the webbing through
loop of elastic material again.
Before proceeding, ensure
that all parts are in the correct
place, are not twisted and that
the buckles function correctly.
6
8. Now pass the webbing over
the centre rib of the buckle
and thread it through the slot
closest to the webbing keeper
that holds the two buckle parts
together.
11. Insert the lower rivet part
through the folded up strap and
connect it to the upper rivet
part it to the upper rivet part.
9. Check the buckle assembly
for correct function before pro-
ceeding.
12. Place the strap on a solid
surface, and use a hammer to
drive the rivet into place.
Repeat the assembly steps
shown in pics 1 to 12 for the
second Hip/Leg connection.
