NOTE
We have used a red replacement part in the images below to enhance its visibility.
The equivalent replacement part included in this kit is black.
1. Remove the used
connection being careful not to
damage any other part of the
harness.
4. Pull the unstitched end of
webbing to form a choked bite
of webbing around the red lying
ring. The cut end of webbing
is now facing away from the
harness.
INSTALLATION, INSTRUCTIONS
2. Thread the replacement web-
bing part under the red lying ring
as shown in the image (the cut
end of webbing is facing the har-
ness). Do not pull the stitching
beyond the ring.
5. Thread the end of the web-
bing through the upper slot of
the front hardware. Take care
to ensure that the webbing
passes from the middle of the
harness toward the outer side
of the harness.
3. Pass the other end of the
webbing part through the loop.
6. Pass the webbing through
loop of elastic material.
