GB
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1-5)
1. Tank indicator
2. Tank cover
3. 2 x 230 V~ socket-outlets
4. Earth connection
5. Safety tripping element
6. Voltmeter
7. Oil filler plug
8. Oil drain plug
9. Oil shortage cut-out
10. On/Off switch
11. Choke lever
12. Reversing starter
13. Petrol cock
14. Wheels
15. Push bar
16. Push bar bracket
17. Feet
18. 4 x M6 x 35 mm screws
19. 4 x washers, bent
20. 2 x M6 x 50 mm screws
21. 4 x washers M6
22. 6 x nuts M6
23. 2 x nuts M10
24. 2 x washers M10
25. 2 x wheel hubs
26. 2 x M10 x 80 mm screws
27. 2 x wrenches
28. Spark plug wrench
29. Screwdriver
14
03.03.2009 13:12 Uhr Seite 14
3. Proper use
The device is designed for applications operated with
a 230 V alternating current source. Be sure to
observe the restrictions in the safety instructions.
The generator is intended to provide electric tools
and light sources with electricity.
When using the device with household appliances,
please check their suitability in accordance with the
relevant manufacturerʼs instructions. In case of
doubt, ask an authorized dealer of the respective
appliance.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Generator
Protection type:
Continuous rated power P
Maximum power P
Rated voltage U
Rated current I
Frequency F
Drive engine design:
Displacement:
Max. power:
Fuel:
Tank capacity:
Engine oil:
Consumption at 2/3 load:
Weight:
Sound pressure level L
Sound power level L
Power factor cos ϕ:
Synchronous
(S1):
rated
(S2 5 min):
max
: 2 x 230V~
rated
:
rated
:
rated
4-stroke, air-cooled
5.1 kW / 7 hp
normal unleaded petrol
approx. 0.6 l (15W40)
approx. 1.8 l/h
: 72.9 dB(A)
pA
/Uncertainty K:
WA
92.9 dB (A)/1.42 dB(A)
IP23
2600 W
2800 W
11.3 A
50 Hz
208 cm³
15 l
49 kg
