What's in the box

This transceiver comes shipped with below items and accessories in the box:
Dual-band Radio
2200mAh Battery
Dual Band Antenna
Desktop Charger
Adapter
Earpiece Kit
Wrist Strap

Belt Clip

User manual
FIND TUTORIALS, SUPPORT AND MORE
https://www.radioddity.com/
https://www.facebook.com/radioddity
https://www.youtube.com/c/Radioddityradio
03

Assembly

Before the radio is ready for use we need to attach thew antenna and battery pack, as well as charge
the battery .

Antenna

This transceiver is fitted with a Male SMA connector. To mount your antenna (Female SMA connector),
align the two connectors and turn clockwise until it stops.
Notice
Please make sure to install the antenna and battery is charged when start using a radio.
Do not over-tighten your antenna to avoid damage to the outer materials and the connect base.
When installing the antenna, please remember to grip it by the base and screw.
When you choose using an external antenna, make sure its SWR is about 1.5:1 or lower to avoid
damage to the transceiver.
Do not hold the antenna with your hand or wrap the outside of it to avoid interference to the transceiver.
Never transmitting without an antenna.
Belt clip
There are two parallel screws mounted on rear radio body, remove them and thread through the holes
on the belt clip as you screw them back into the radio body.
Do not add any form of glue to fix the screws on the battery clip.
The solvents in the glue may cause damage to the battery casing.
