Page 1 of 10 CP0557 FITTING INSTRUCTIONS FOR CP0557 CRASH PROTECTORS PICTURE A HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
Seite 2
Page 2 of 10 CP0557 TOOLS REQUIRED GENERAL TORQUE SETTINGS Socket set including a 17mm socket M4 BOLT = 8Nm • • Ratchet M5 BOLT = Torque wrench (up to 50Nm). • M6 BOLT = M8 BOLT = 20Nm 0 BOLT = 40Nm...
Seite 3
Page 3 of 10 CP0557 PICTURE B FITTING INSTRUCTIONS Before removing engine bolts, ensure the bike is upright and supported by a suitable engine stand or jack placed under the sump of the motorbike to support the partial weight of the engine, this will prevent the engine from moving during fitting.
Seite 4
Page 4 of 10 CP0557 See more R&G products for your Motorcycle On: ISSUE 1 - 23/08/2023 (JH) CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
Seite 5
Page 5 of 10 CP0557 NOTICE DE MONTAGE POUR CP0557 PROTECTIONS CRASH PHOTO A E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS E PAS PROCEDER AU MONTAGE TANT QUE VOUS N...
Seite 7
Page 7 of 10 CP0557 PHOTO B NOTICE DE MONTAGE Avant de retirer les boulons du moteur, assurez-vous que la moto soit droite et soutenue par un support moteur ou un cric approprié placé sous le carter de la moto pour supporter une partie du poids du moteur, cela évitera que le moteur bouge pendant le montage.
Seite 8
Page 8 of 10 CP0557 MONTAGEANLEITUNG FÜR CP0557 STURZPADS BBILDUNG A EILE SIND AUF DEN NACHFOLGENDEN EITEN ABGEBILDET UND GEKENNZEICHNET IE ABGEBILDETEN EILE DIENEN LEDIGLICH ZUR RKLÄRUNG Ü BERPRÜFEN IE ZUERST DASS ALLE EILE VORHANDEN SIND ESEN IE DIE ONTAGEANLEITUNG KOMPLETT DURCH...
Seite 10
Page 10 of 10 CP0557 ABBILDUNG B MONTAGEANLEITUNG Bevor Sie mit der Montage der R&G Sturzpads beginnen, stellen Sie sicher, dass das Motorrad aufrecht steht und der Motor von unten mit einem geeigneten Ständer/Heber unterhalb der Ölwanne gestützt wird. Dies wird verhindern, dass der Motor sich bei der Entfernung von Motorschrauben bewegt.
