Tietzsch ProfiSafe LSP 4L Bedienungsanleitung Seite 12

2
5
1 Test electrodes
2 Red LED (LV indication)
for voltages ≥ 50 V AC / 120 V DC
3 Green LED „Ω" signalizes continuity
0 ... 1000 kΩ
4 Indication of rotating field arrow left/right
5 Display (LCD)
6 Handgear
7 Connecting line
Symbols on the instrument
Attention! Observe user instructions!
Mark of approval from VDE test authority
Indicates EC conformity
TR
On-time at highest nominal voltage
on
RT
Recovery time after tests with highest nominal voltage
off
Device for live working
This devices may not be disposed with the domestic
waste (WEEE 2012/19/EU).
Please contact service@tietzsch.de in regard to the return
of old devices.
