3

Specifications

3.1

Technical specifications

Rotational speed
Measuring range
Accuracy
Repeatability
Displayed data
Rotors
Power supply
Battery life
Operating conditions
Pollution degree
Protection class
Dimensions
Weight
Viscosity table
Measuring range (dPa
Rotor
s)
0.3 ... 13 dPa s
R3
3 ... 150 dPa s
R1
100 ... 4,000 dPa s
R2
3.2

Contents of delivery

1 x viscometer PCE-RVI 7
1 x set of rotors (R1, R2, R3)
1 x calibration certificate
1 x measuring vessel (no. 3; capacity 170 ml)
4 x 1.5 V AA batteries
1 x spindle protector
1 x instruction manual
1 x carrying case
3.3

Optional accessories

Calibration oils (500 ml)
Manual
fixed speed at 62.5 rpm
Rotor 3: 0.3 ... 13 dPa s // 30 ... 1,300 mPa s
(with measuring vessel no. 3)
Rotor 1: 3 ... 150 dPa s // 300 ... 15,000 mPa s
(with measuring vessel no. 3)
Rotor 2: 100 ... 4,000 dPa s // 10,000 ... 400,000 mPa s
(with measuring vessel no. 3)
±2 % f.s.
±1 %
rpm (fixed at 62.5 rpm)
selected rotor (R1 – R3)
dynamic viscosity (mPa s / dPa s)
full scale range
full scale percentage
battery level indicator
3 different rotors included (R1, R2, R3)
4 x AA LR6 or R6 batteries (6 V)
24 ... 30 hours of continuous operation
+10 ... +40 °C
≤80 % RH, non-condensing
max. 2,000 m above mean sea level
2
IP 20
170 x 110 x 410 mm
1.8 kg
Measuring range (mPa s)
30 ... 1,300 mPa s
300 ... 15,000 mPa s
10,000 ... 400,000 mPa s
4
Measuring Sample
vessel capacity
No. 3 ±170 ml
No. 3 ±170 ml
No. 3 ±170 ml
