Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety regulations with due care. Keep this manual in
a safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety
regulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
Explanation of the plate (see Fig. 13)
1. Warning
2. Keep out of the rain and protect from
getting wet.
3. Read the operating instructions before using for
the first time.
4. Pull the plug from the power supply
immediately if the cable gets damaged or
severed.
5. Wear goggles and ear muffs.
2. Layout (see Fig. 1)
1. Cutter rail
2. Hand guard
3. Steady grip with button switch
4. Handle with button switch at the top and bottom
5. Cable grip
6. Power cable
7. Cutter guard
8. Impact guard
9. Cuttings collector
10. Fixing screw
Important! You must never use the hedge
trimmer without hand guard.
31.07.2008 7:30 Uhr Seite 9
3. Proper use
Important! This hedge trimmer is designed for the
trimming of hedges, bushes and shrubs.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Voltage
Power consumption
Cutting length
Cutter rail length
Tooth spacing
max. cutting ø
Cuts/min
Sound power level L WA
Sound pressure level L pA
Vibration a hv
Weight
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
b Rotary rear handle (Figures 2-4)
The hedge shears are fitted with a rear rotary
handle. This can be turned counter-clockwise
through 90° and clockwise through both 90° and
180°. For this purpose the top slide (Fig. 2/Pos.
1) must be pushed backwards in the direction
indicated by the arrow. Then pull the slide (E) in
the direction indicated by the arrow and turn the
handle. If you turn it counter-clockwise the
handle will lock at an angle of 90° (Fig. 3). If you
turn it clockwise the handle will lock at an angle
GB
230V ~ 50Hz
600 W
530 mm
600 mm
20 mm
15 mm
3200/min
88,6 dB
96 dB
4,2 m/s 2
4,0 kg
