Showlasers must provide a manual safety shutdown enabling to interrupt the laser radiation at any time by
force. If the laser product is installed in the trussing system or in an unaccessible location, it must at least be
installed with a switchable power outlet.

5.4 Adjusting the laser

Switch the device on via the power switch.
Loosen the fixation screws of the mounting bracket and adjust the laser product to the desired projection
area.
Call up all desired projection patterns in order to make sure that the projections only move in the
inaccessible showlaser area.
Make sure that no mirrorballs, shining surfaces etc. are located in the laser beam. Shining objects must be
removed from the laser area or be covered.
Tighten the fixation screws of the mounting bracket so that the laser beam cannot be moved without tools.

6. OPERATION

With the POWER-switch, you can switch the device on and off.
Turn the keyswitch to ON.
Spatial effects of the projection patterns can be created by using a smoke-machine. Make sure that you do
not use too much smoke so that the laser beam is swallowed after a short distance and the audience cannot
see the projections.

7. CLEANING AND MAINTENANCE

Laser products in discotheques are technical working installations and fall under the Equipment Safety Act.
This is why they must fulfill its requirements.
The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
Always disconnect from the mains when the device is not in use or before cleaning it.
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
Clean the front glass every two weeks from dust and smoke fluid residues.
There are no servicable parts inside the device. Never open the housing! Maintenance and service
operations are only to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
25/26 00051281.DOC, Version 1.1
