Libra
If the optimal position is reached
please fasten the screws of the seat
cushion in the front most position
first. Afterwards please fasten all the
remaining screws equally.
At the next step the front part from
the side frame will be adjusted in
order to match the already fixed seat
cushion. Please fold the wheelchair
first and unscrew all the six screws of
the front part of the side frame.
After unscrewing and disassembling
all the screws you can pull out each
side in driving position. Please note
the different bores at the inner
horizontal tube preset the
adjustment.
The optimal positioning of the side
frames is reached if the bushings
used for the foot rests end with the
seat cushion. As a last step please
fasten all the screws from the side
frame.
