Libra

Adjustment backrest angle

The backrest can be adjusted
variable supported by two gas
springs. Angle range = 0° - 70°
To avoid that the wheelchair rolls away please lock both locking brakes at a
first step. Hold both grip handles firmly and pull the adjustment lever at the
right side. Then push the backrest downwards until the ideal position is
reached and release the lever at the same time. Now the backrest is
adjusted tight. In contrast pull the release lever and push the backrest in
driving position. The two gas springs support by tilting up.
42 07/2012/Rev.01
