Ice-Maker - Beko GN162330XBN Bedienungsanleitung

Using the product

6.16 Ice-maker

(Optional)
Ice maker is located on the upper section of the
freezer cover.
Hold the handles on the sides of the ice stock
reservoir and move up to remove.
Remove the ice-maker decorative lid by moving
up.
OPERATION
To remove the ice reservoir
Hold the ice stock reservoir from the handles, then
move up and pull the ice stock reservoir.
To reinstall the ice reservoir
Hold the ice stock reservoir from the handles, move
up with an angle to fit the sides of the reservoir to
their slot and make sure that the ice selector pin is
mounted properly. (Figure 2)
Push downwards firmly, until there is no space left
between the reservoir and the door plastic. (Figure 2)
If you have difficulty in refitting the reservoir, turn
the rotary gear 90° and reinstall it as shown in the
figure3.
Any sound you hear when the ice drops into the
reservoir is a part of normal operation.
When the ice dispenser does not work
properly
If you do not remove ice cubes for a long time, they
will cause formation of ice chunks. In this case,
please remove the ice stock reservoir in accordance
with the instructions given above, seperate the ice
chunks, discard the inseparable ice and put the ice
cubes back into the ice stock reservoir. (Figure 4)
28 /36 EN
Refrigerator / User Guide
