No. Art No. Description
1 58-366 Middle frame
2 - Widening assembly Bure Double,
R&G, see seperate view
3 58-335 Telescopic Inner pipe
4 58-365 Top frame
5 - Included in 58-366
6 56-340 Guide sleeve
57-310 Middle frame bushing
7 58-379-L Bottom beam left Bure double
8 58-379-R Bottom beam Right Bure double
9 57-306 PU Armrest cushion Right
10 57-305 Armrest cushion Right
11 57-049 Castor wheel 125mm brake
57-319 Castor wheel 100mm brake
57-051 Castor wheel 75mm brake
12 57-775 Dome cover wheel
13 57-776 Dome cover wheel top
14 58-360 Cover Wheel attachment
15 57-041-3 Holder remote control Bure double
16 58-373/ Control box 220V Digital Li-On
Lion TiMotion Bure
17 58-389 Battery box 4.0 Ah TBB5/Li-On,
see seperate view
18 56-353 Bure Handle assy
19 57-919 Star knob handle
20 57-917 Wing nut
21 58-338 Bushing middle frame
22 56-308 Cable holder Bure charger
23 57-639 Screw K6S M6x8
24 57-805 Washer BRB 6,4x12x1,6
25 57-817 Lock nut CL6 M10
26 57-825 Washer 10,5×18×2
27 57-848 Nordlock 10,7x21x2,5
I F U
No. Art No. Description
28 57-787 Washer 10x25x1,5
29 57-885 Screw MF6S M6x10
30 57-811 Serrated lock washer M16
31 57-803 Locking washer M10 6.1x11.8x1.6
32 57-816 Screw MC6S M10x40
33 57-804 Washer 22×6,5×8
34 57-808 Pin bolt M6x25
35 57-792 Screw MC6S M8x35
36 57-806 Washer 8.4x16x1.5
37 57-812 Tapping screw RXS 2,9x4,5
38 57-769 Washer 12,5x35x2
39 57-766 Lock nut CL6 M12
40 57-879 Cap nut M6
41 57-864 Screw K6S M6x20
42 57-884 Screw MC6S M10x45
43 58-354-1 Wheel attachment
44 57-801 Lock nut M8
45 58-326 Spiral Cord EUR - T-Motion, Bure
46 58-374-X2 Hand control TiMotion TH7
47 58-377 Actuator Timotion 2000N/5200rpm
Bure
48 57-904 Washer 6.4x12.5x2 nylon
49 57-828 Pop rivet AL/ST 4,8x10
50 57-369 Battery clamp Alu
51 57-370 Battery bracket Alu
52 57-883 Screw MF6S M6x40
53 57-878 Screw K6S M6x25
