6. Technical Specifications

Control box
Batteries
Lifting Actuator
Widening Actuator
Hand Control
IP class
Material
Castors
Weight
Expected Service life
Max patient weight
Operating environment
Storage and transportation
environment
Materials in contact with
human skin
Applied parts:
P - patient, C - caregiver
x X
I F U
TiMotion Voltage in 220V-240VAC, Voltage out 24V, 50Hz, 1250mA, 70VA, Encapsu-
lation IP66, Electrical safety Class II (Double insulated) Duty cycle: 10%, Max. 2min.
ON/18 min./OFF
TiMotion Rechargeable Li-Ion Battery, 24 V - 4A, 96Wh, Encapsulation IP66, Capacity
4,0Ah, Cable length 600mm. Duty cycle: 10%, Max. 2min. ON/18 min./OFF
TiMotion 24VDC, Max 8,0A, Push: 2000N, Pull: 2000N, Self-locking capacity (min):
1000N, Current: 6.6 (+/-1,0)A, Stroke 400mm +/-2mm, Mounting dim. 605mm,
Encapsulation IP66. Duty cycle: 10%, Max. 2min. ON/18min. OFF
TiMotion 24 VDC, Max 8,0A, Push: 1000N, Pull: 1000N Self-locking capacity (min):
1000N, Current: 2.6 (+/-0,4)A, Stroke 55mm +/-2 mm, Mounting dim. 167mm,
Encapsulation UIP.
Duty cycle: 10%, Max. 2min.ON/18min. OFF
Cable length straight 300mm + coiled 400 mm, IP66
IPX5
Steel
125/100/75mm
33kg
8 years
150 kg / 330 Ibs
5 °C to 40°C, relative humidity 20% to 80% non-condensing, and atmospheric
pressure 700 to 1060 hPa.
5 °C to 50 °C, relative humidity 20% to 80% non-condensing, and atmospheric.
Environment pressure 700 to 1060 hPa.
Materials that user and operator/caregiver are exposed to during usage of the pro-
duct for prolonged time:
Poroflex (synthetic leather cushions) P
Polyurethane (on PU cushions) P
Dryflex (handles) P
PA6 + 20% GF (brake lever) P
Hand control C
X
Armrest P
Handles P
Knee pad P
Foot rest support P
Foot rest support clamps C
Handles adjusting knobs C
Hand controller and its holder. C
Handles to adjust the armrest width. C
Hand control C
Charger C
Charger cable C
Footplate
x
