Raising/Lowering the Frame
The desired height is adjusted with Arrow <UP> or Arrow <DOWN>. Adjust bottom frame
using <WIDER> arrow or <NARROWER> arrow
Handset Plus has charge indicator / battery (low, medium, high) and Service indicator (see fur-
ther under "Hand Control Plus").
Adjusting the Handles
To adjust handles to the desired position; loosen screw, adjust handle, tighten screw.
Left and Right Adjustment of Armrests
The armrests can be adjusted sideways for optimal support; loosen screw, adjust armrest,
tighten screw.
NOTE: The rear attachments on the frame/armrest are interchangeable (left with right and vice
versa) to provide different widths. The locating pins on the cushion's underside/rear can also be
moved. These adjustment capabilities make customisation possible.
Using the Parking Brakes on Castor Wheels
When parking the device, activate the parking brake on the lockable castor wheels.
Lock the wheels by pressing the green pedal brake down with your foot. To release the
brake, press the green protruding part with your foot. The caregiver should assist the
patient in activating the parking brake in case the patient cannot activate them him or
herself.
Using Hand Brakes
Running brakes: Pull the brake levers towards you to reduce speed.
You will brake the rear wheel that is located on the same side as the brake lever.
If you apply only one of the brakes, the walker will turn to that side. When the lever is
released, the braking will stop. Do not use the brakes continuously while the walker is
in motion.
Parking brakes: Push the brake levers forwards from you to activate the parking brakes.
Be aware that the lever has some resistance before it stops and locks the rear wheel.
Pull the brake levers back towards you to release the parking brakes.
Hand Control Plus
**1. Service indicator – flashes red after 11 months' operation.
Constant light (red) after 12 months' operation.
The indicator is a reminder to review the maintenance instruction (see Maintenance
Instructions). This should be done at least once every 12 months.
Reset: hold down buttons <2a> + <2b> for at least 30 seconds. **The indicator will go out
around 30 seconds after the hand control is activated (battery conservation function).
6
2a 2b
1
