USE
tween 0° and 45°. They are used in the production of picture frames, for carving mouldings, making
boxes with sloping sides and for carpentry work. Always make a test cut on a piece of spare wood
first.
1. Pull out the lock (4) and raise the arm (3) to its full height.
2. Release the angle fixing handle (20) and press the stop (21). Now turn the table (16) to the re-
quired position.
3. Secure the angle by turning the angle fixing handle (20) and releasing the stop (21).
4. Loosen the vertical angle locking screw (12) and tilt the saw arm (3) to the left to the desired angle.
Tighten the locking screw (12).
5. Place the material to be cut on the table with one edge pressed against the stop rails (14). If the
material is not level, rest the convex side against the stops (14). In the opposite arrangement, the
material may break during cutting and block the saw.
6. When cutting longer pieces, it is necessary to support them with the help of machine supports or
suitable external support or table in the same height, etc.
7. Before switching on the machine, make sure that the material moves freely and does not hit parts
of the saw, clamp, surrounding objects, etc., and that the saw also reaches freely from the cut.
8. Hold the saw firmly by the handle (5), flip the switch lock (30) and press the switch (19). Let the
engine run at full speed and then gradually lower the saw into the cut.
9. When you have finished cutting, release the switch (19) and let the engine stop before lifting the
saw out of the cut. The disc must be stopped completely before removing the material to be cut.
Cutting wider material
For longer cuts, release the feed lock (24) and move the saw arm back and forth.

CUTTING DEPTH ADJUSTMENT

You can set the depth of the cut for evenly shallow cuts and repeated cuts.
1. Slide the depth of cut stop (26) to the front position.
2. Loosen the depth adjustment screw nut (27) to loosen the screw (25) and turn it until the saw teeth
reach the specified depth.
3. Hold the saw arm in this position and tighten the nut (27) to secure the position of the screw (25).
4. Check the depth of the cut again by moving the saw head over the entire feed range or making
a test cut.
MAINTENANCE
WARNING: Unplug the power cord before making any adjustments, repairs, or maintenance.
1. After making any adjustments, adjustments, or maintenance, always make sure that all bolts are
securely tightened, the covers, locks, and pins in place, and all wrenches and tools are securely
removed.
2. Keep engine vents clean and uncovered. Sometimes you can see sparks through the holes. This is
normal and does not damage the machine.
3. Regularly check the motor grilles and the switch area and clean any dust, chips and material resi-
dues. Remove dust with a soft brush.
4. Protect your eyes with goggles when cleaning.
5. Clean the machine body with a soft, dry cloth. Remove heavy soiling with a mild detergent solu-
tion. Do not use any chemicals, solvents or alcohol.
ENGLISH 15
