USE
The stop (21) allows quick adjustment of fixed angles 0°, 15°, 22.5°, 30° and 45°.
MITER CUTS
The vertical angle locking screw (12) allows the vertical angle of the saw to be adjusted. This angle
can be adjusted between 0° and 45° to the left. Before adjusting the angle, loosen the screw, adjust
the saw to the desired angle, and then retighten the screw.
SPINDLE LOCK
The spindle lock (22) allows you to stop the motor from rotating when the disc is mounted. First, press
and hold it and rotate the spindle until it clicks. Keep it pressed while loosening and tightening the
saw disc screw.
Never press it while the machine is running!
MOVABLE
The movable disc guard (8) covers both sides of the saw and automatically rises over the top cover
when the arm is pushed into the cut.

SWITCHING ON AND OFF

• To switch on the machine, push the switch lock (30) to the left and press the switch (19).
• The motor stops when the switch (19) is released.
USING THE LASER
Switch the laser (1) on and off with the laser switch (2). Press position "I" to turn on the light, press at
the point marked "0" to turn it off again.

SAW ADJUSTMENT

1. Make sure that the machine is disconnected from the mains.
2. Push the arm (3) down to the lowest position and secure it with the lock (4).
3. Release the handle (20) and press the angle lock (21).
4. Turn the table (16) to the 0° position on the scale.
5. Release the lock (21) and let it lock and tighten the handle (20).
6. Loosen the vertical angle screw (12) and set the vertical arm angle (3) to 0° (90° to the table). Then
tighten the lock (12).
7. Place the angle on the table (16) and rest it on the flat part of the saw disc.
8. Turn the disc by hand and check it is perpendicular at several points. The edge of the angle and
the surface of the disc must be parallel.
9. If the saw disc is not perpendicular to the table, adjust the angle as follows:
10. Use a 10 mm wrench to loosen the 0° vertical angle stop (29). Also, loosen the vertical angle lock-
ing screw (12).
11. Using a 4 mm Allen key, adjust the vertical angle stop 0° (29) so that the saw is perpendicular to
the table.
12. Loosen the vertical angle scale screw (13) and adjust the scale so that the pointer corresponds to
an angle of 0°. Tighten the support screw.
13. Tighten the vertical angle locking screw (12) and the vertical angle stop 0° (29).
12 ENGLISH
SAW DISC PROTECTION
