ASSEMBLY
SAWDUST OUTPUT
To reduce dust and increase cutting efficiency, the machine is equipped with a dust outlet. This can
be connected to an extractor or equipped with a sawdust trap.
The relevant bag is included in the accessories. Simply thread it onto the sawdust outlet neck on the
top cover of the saw.
Clean the used bag after removing it from the machine and opening the zipper.
Note: to ensure optimal function, clean the bag no later than when it is 2/3rds full.
ASSEMBLY HOLES
Before use, it is necessary to fasten it to a solid flat surface with 4 screws (not included).
The base of the machine has holes for attaching the machine to a work table or other suitable base.
Proceed as follows:
1. Place the machine in position and mark the position of the mounting holes.
2. Remove the machine and drill 4 holes in the washer.
3. Place the machine back on the holes and fasten it with suitable bolts, nuts and washers.
Attention: make sure the base is not tilted. An uneven and sloping surface leads to jamming of cut
objects and uneven cuts.
CLAMP
The material to be cut should always be fastened with the enclosed clamp.
EXTENSION SUPPORTS
When cutting long materials, slide the supports out of the machine and secure them by tightening
the appropriate elements.
USE
Arm lock
When transporting or storing the machine, the saw arm should be locked in the lower position by
means of a lock. The arm must be released before use: Push the arm down and release the arm lock
(4) by turning it with the other hand. Then release the arm.
The machine must never be used with a secured arm.
To return the machine to the locked position, reverse the procedure: push the arm down and clamp
it with the lock (4), then lock by turning it.

TRANSPORT

• Before transporting the machine, the arm must be locked in the down position.
• It is also necessary to tighten the other locking screws: the angle fixing handle (20), the vertical
angle screw (12) and the feed lock (24).
• The machine must be switched off and the power supply unplugged.
• Lift the machine by the handle or base. Never pull on the protective covers.
TABLE ROTATION LOCK
The handle with the angle fixing screw (2) is used to lock the table at any selected cutting angle. You
can select this angle from 0° to 45° on both sides. Adjust the angle by releasing the handle (20) and
pressing the stop (21) by turning the table to the desired position.
