Spezifikationen
,EVT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER
=5,EVT_DISPLAY=6,EVT_CONSOLE=7}"
linesensor {line_num} events type show
linesensor {line_num} maxval set {float}
linesensor {line_num} maxval show
linesensor {line_num} minval set {float}
linesensor {line_num} minval show
linesensor {line_num} hyst set {float}
linesensor {line_num} hyst show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port set {port_num}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state set {OFF=0|ON=1|DISABLED=2}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state show
linesensor beeper set {OFF=0|ON=1}
linesensor beeper show
modbus
modbus enabled set <off=0/on=1>
modbus enabled show
modbus port set <ip_port>
modbus port show
port
port {port_num} state set {OFF=0|ON=1}
port {port_num} state show
port all state set "{port_list}" {OFF=0|ON=1}
port all state {MODE0=0|MODE1=1|MODE2=2}
show
port {port_num} reset
port {port_num} toggle
port {port_num} batch set {OFF=0|ON=1} wait
{num_secs} {OFF=0|ON=1}
port {port_num} batch cancel
port {port_num} label set "{name}"
port {port_num} label show
port {port_num} initstate coldstart set {OFF=0|
ON=1|REMEMBER=2}
port {port_num} initstate coldstart show
port {port_num} initstate delay set {num}
port {port_num} initstate delay show
port {port_num} gsm pin set "{pin_num}"
port {port_num} gsm pin show
port {port_num} repowerdelay set {num}
port {port_num} repowerdelay show
port {port_num} resettime set {num}
port {port_num} resettime show
port {port_num} watchdog enabled set {OFF=0|
ON=1}
port {port_num} watchdog enabled show
port {port_num} watchdog mode set {OFF=0|
PORT_RESET=1|IP_MS=2|IP_MS_INV=3}
port {port_num} watchdog mode show
port {port_num} watchdog type set {WD_ICMP=0|
WD_TCP=1}
port {port_num} watchdog type show
port {port_num} watchdog link down set {OFF=0|
ON=1}
port {port_num} watchdog link down show
port {port_num} watchdog host set "{dns_name}" sets port watchdog host target
port {port_num} watchdog host show
port {port_num} watchdog port set {ip_port}
port {port_num} watchdog port show
port {port_num} watchdog pinginterval set {num}
port {port_num} watchdog pinginterval show
port {port_num} watchdog pingretries set {num}
port {port_num} watchdog pingretries show
port {port_num} watchdog retrybooting set
{OFF=0|ON=1}
Expert Power Control 8032
LEGACY - shows what event types are enabled
LEGACY - sets maximum value for line meter
LEGACY - shows maximum value for line meter
LEGACY - sets minimum value for line meter
LEGACY - shows minimum value for line meter
LEGACY - sets hysterese value for line meter
LEGACY - shows hysterese value for line meter
LEGACY - sets Port for Power Port Switching acti-
ons
LEGACY - shows Port for Power Port Switching
actions
LEGACY - sets Port state for Power Port Swit-
ching actions
LEGACY - shows Port state for Power Port Swit-
ching actions
enables beeper for line meter alarms
shows if beeper for line meter alarms is enabled
enters cmd group "modbus"
enables Modbus TCP support
shows if Modbus is enabled
sets Modbus TCP port
shows Modbus TCP port
enters cmd group "port"
sets port to new state
shows port state
sets several ports in one cmd - e.g. port all state
set "1,3,5" 1
shows all port states in 3 different view modes
start reset sequence for port
toggles port
starts batch mode for port
cancels batch mode
sets port label name
shows port label name
sets port coldstart initialization
shows port coldstart initialization
sets port init delay
shows port init delay
sets the individual port access code
shows the individual port access code
sets port repower delay
shows port repower delay
sets port reset duration
shows port reset duration
sets port watchdog to on/off
shows port watchdog state
sets port watchdog mode
shows port watchdog mode
sets port watchdog type
shows port watchdog type
sets if watchdog active when eth link down
shows if watchdog active when eth link down
shows port watchdog host target
sets port watchdog TCP port
shows port watchdog TCP port
sets port watchdog ping interval
shows port watchdog ping interval
sets port watchdog ping retries
shows port watchdog ping retries
sets port watchdog retry booting to on/off
L
L
L
L
L
L
L
L
L
L
L
4
