GUDE Systems Expert Power Control 8032 Serie Anleitung Seite 73

Spezifikationen
epc8032PowerApparent
epc8032PowerReactive
epc8032AbsEnergyReactive
epc8032AbsEnergyActiveResetta-
ble
epc8032AbsEnergyReactiveReset-
table
epc8032ResetTime
epc8032ForwEnergyActive
epc8032ForwEnergyReactive
epc8032ForwEnergyActiveReset-
table
epc8032ForwEnergyReactiveRe-
settable
epc8032RevEnergyActive
epc8032RevEnergyReactive
epc8032RevEnergyActiveResetta-
ble
epc8032RevEnergyReactiveReset-
table
epc8032ResidualCurrent
epc8032ResidualCurrentRMS
epc8032ResidualCurrentDC
epc8032LineSensorName
epc8032OVPIndex
epc8032OVPStatus
epc8032CPUSensorVsystem
epc8032CPUSensorVaux
epc8032CPUSensorVmain
epc8032CPUSensorTcpu
epc8032NTPTimeValid
epc8032NTPUnixTime
epc8032NTPLastValidTimestamp
epc8032SensorIndex
epc8032TempSensor
epc8032HygroSensor
epc8032AirPressure
epc8032DewPoint
epc8032DewPointDiff
73
Expert Power Control 8032
.82.1.5.1.2.1.10.x
L Line Mean Apparent Power
.82.1.5.1.2.1.11.x
L Line Mean Reactive Power
.82.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.82.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all resetta-
ble counter.
.82.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.82.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.82.1.5.1.2.1.16.x
Forward Active Energy counter.
.82.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.82.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.82.1.5.1.2.1.19.x
Resettable Forward Reactive Energy counter.
.82.1.5.1.2.1.20.x
Reverse Active Energy counter.
.82.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.82.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.82.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.82.1.5.1.2.1.24.x
Actual Residual Current on Power Channel. According Type A IEC
60755. Only visible on models that support this feature.
.82.1.5.1.2.1.25.x
Actual Residual Current RMS on Power Channel. According Type B IEC
60755. Only visible on models that support this feature.
.82.1.5.1.2.1.26.x
Actual Residual Current DC on Power Channel. According Type B IEC
60755. Only visible on models that support this feature.
.82.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.82.1.5.2.1.1.x
None
.82.1.5.2.1.2.x
shows the status of the built-in Overvoltage Protection
.82.1.5.14.1.0
System Voltage on CPU Board
.82.1.5.14.2.0
Auxiliary Voltage on CPU Board
.82.1.5.14.3.0
Main Voltage on CPU Board
.82.1.5.14.4.0
Temperature on CPU Board
.82.1.5.15.1.0
Show if valid Time is received
.82.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
.82.1.5.15.3.0
show seconds since last valid NTP timestamp received
.82.1.6.1.1.1.x
None
.82.1.6.1.1.2.x
actual temperature
.82.1.6.1.1.3.x
actual humidity
.82.1.6.1.1.5.x
actual air pressure
.82.1.6.1.1.6.x
dew point for actual temperature and humidity
.82.1.6.1.1.7.x
difference between dew point and actual temperature (Temp - De-
wPoint)
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
OCTETS RW
Integer32 RO
INTEGER RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
INTEGER RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
