RAC 182
No. CODE Q.ty
1 72000322 1 Handgrip
2 72000364 1 Riveting tool body
3 711259 1
Service plug
4 712117 1 Washer stopping spring
5 710841 1 Valve
6 710916 1 Gasket OR 2-015
7 713390 2 Gasket OR 2-007
8 72000457 1 Pneumatic cylinder
9 72000323 1 Hydraulic cylinder
10 711730 1 Gasket OR 2-119
11 71346103 1 Hydraulic piston
12 710917 1 Gasket OR 2-118
13 711974 1 Seeger ring JV 22
14 710901 1 Gasket B-102070
15 710908 1 Washer
16 71C01698 1 Gasket B-086055 (B/NEI)
17 71346101 1 Front connector
18 710300 1 Gasket OR 020
19 710579 1 Gasket OR 2-113
20 711729 1 Gasket OR 2-024
21 710102 1 Gasket OR 113
22 710859 1 Clamps holding cone
23 710555 1 Washer 400-004-4490
24 71C01278 1 Screw TBCE M6 x 6 ISO 7380
25 71346060 1 Sleeve carrying nozzle
26 717004 1 Nozzle for rivet ø 4,8 Cu / Steel
27 710853 1 Spring
28 710849 1 Clamps opener
29 71345507 3 High-performance clamp
30 710003 2 Gasket OR 5-052
31 711706 1 Nails container
32 711336 2 Gasket OR 2-114
33 711357 1 Wrench kit
34 71346455 1 Bush
35 71346453 1 Rod
36 71346470 1 Silencer
37 710528 1
Gasket OR 008
38 71346452 1 Rod guide
39 71C01297 1 Gasket OR 2-043
40 71C01296 1 Seeger ring 100 UNI 7437
41 71346085 1 Protection bottom
42 71346469 1 Tube ø 8 x 7
43 711339 1 Gasket OR 2-129
44 71346084 1 Protection bottom
45 716377 1 Connector 6522 - ø 10 - 1/4"
46 71C01022 1 Cap 1/4"
47 71346107 1 Balancer hook
48 711732 1 Gasket OR 2-118
49 710258 1 Gasket OR 5-612
50 710350 4 Gasket OR 2-109
51 717001 1 Nozzle for rivet ø 2,4 ÷ 3,4
52 717002 1 Nozzle for rivet ø 4
53 717003 1 Nozzle for rivet ø 4,8 All.
54 717005 1 Nozzle for rivet ø 6 / 6,4
55 717006 1 Nozzle for rivet ø 2,4
56 72A00053 1 Oil container assembly
57 712329 1 Reduction
58 71345212 1 Nails baffle
59 71C01495 2 Gasket OR 4 x 1,5
60 71C01496 1 Gasket OR 3 x 2
61 710822 1 Valve piston
62 710905 1 Seeger ring 11 UNI 7437
63 710922 2 Gasket OR 018
64 712268 1 Spring guide plug
65 710402 1 Seeger ring 22 UNI 7437
66 710837 1 Screw TE M9 x 20
67 710918 2 Gasket OR 2-005
68 711704 2 Valve piston
69 710919 2 Gasket OR 2-004
70 710376 2 Gasket OR 2-009

SPARE PARTS

DESCRIPTION
KIT
75036128 - RAC182 – rev 02 - ( 12-2021 )
GB
No. CODE Q.ty
71 711703 2 Valve body
72 710385 1 Gasket OR 2-006
73 710572 1
Gasket OR 2-120
KITA 740821 Anti-extrusion ring kit
KITB 74000030 Pneumatic piston kit
KITC 740840 Coil kit
KITD 74000088 Cone holder kit
KITF 74000113 Dampener kit
KITG 741702 Plate kit
KITH 74000114 Lever kit
KITM 74000116 Kit back connector
KITP 74000117 Suction adjustment Kit
KITQ 74000119 Gaskets kit
It indicates that the part is sold in kits consisting of
KIT
different parts in different quantities.
DESCRIPTION
KIT
KIT
