QSC DPA4.2 Benutzerhandbuch Seite 11

Four-Channel Configuration
F1: A B C D
F1: A B C D
M
Connect the Loudspeakers
ARNINNG!: When the AC Power is on, there is a potential of having
dangerous voltage at the output terminals on the rear of the amplifier. Use
caution to not touch these contacts. Turn off the AC Mains disconnect switch
prior to making any connections.
EN
1. Turn the AC Mains power switch, on the back of the amplifier, to OFF.
2. Connect the loudspeaker wiring to the 8-pin Euro-style connector. Refer to
thru Figure 17.
3. Install the Euro-style connector onto the rear of the amplifier as shown in
4. Use a Phillips screwdriver to secure the connector.
TD-000434-00-B
A M B M C M D
A Single
B Single
C Single
D Single
— Figure 17 —
Figure 9
Figure 18.
11
— Figure 18 —
