7. Outputs
Caution! Check the voltage and current ratings of
the device you want to connect (e.g. mobile pho-
ne, notebook). Observe the operating instructions
for the device.
The supply time varies according to the level
of the charge of the jump start power bank, the
level of power consumption and the intensity of
use of the connected device. The battery needs
charging when the remaining charge is 40-50% (2
LED shine) (see section 5).
7.1 Charging/operating devices with a USB
connection
1. Connect an available (or the supplied) USB
connection cable to the USB connection (Fig.
1 / Item 4) on the jump start power bank and
then to the device you want to connect.
2. Press the ON/OFF button (Fig. 1 / Item 3).
7.2 Operating 12 V d.c. devices
1. Connect the supplied connection cable (Fig.
2d / Item 13) to the 12 V d.c. outlet (Fig. 1 /
Item 5) on the jump start power bank and
then to the 12 V d.c. device, using the sup-
plied connector (Fig. 2d / Item 14) if neces-
sary. The maximum power consumption must
not exceed 10 A.
2. Press the ON/OFF button (Fig. 1 / Item 3).
7.3 Operating 19 V d.c. devices
1. Connect the supplied connection cable (Fig.
2d / Item 13) to the 19 V d.c. outlet (Fig. 1 /
Item 1) on the jump start power bank and
then to the 19 V d.c. device, using the sup-
plied connector (Fig. 2d / Item 14) if neces-
sary. The maximum power consumption must
not exceed 3.5 A.
2. Press the ON/OFF button (Fig. 1 / Item 3).
8. Jump starting for the vehicle
The 12 V jump starting function provides welcome
help with starting diffi culties due to too little batte-
ry capacity.
Warning! Only the jump start cable is allowed
to be connected during jump starting. Any power
supply to a connected device, e.g. via the USB
connection, must be disconnected fi rst.
We would like to point out that vehicles are fi tted
with a whole host of electronic equipment. Please
also refer to the instructions in the owner's manu-
Anl_CC_JS_12_SPK7.indb 16 Anl_CC_JS_12_SPK7.indb 16
GB
als for the car, radio, etc.
Warning! Never connect to the vehicle body-
work!
•
Make sure that the connector on the jump
start cable is securely connected to the de-
vice socket. If the connection is loose during
jump starting, the connector could melt as a
result of the high current.
•
The poles on the vehicle battery must be
clean and the clamps of the jump start cable
must be securely attached to the battery
poles.
•
Do not connect the clamps of the jump start
cable together during jump starting – short-
circuit.
Check that at least 3 LED of the battery capacity
indicator are lit. The equipment temperature must
be within the range of + 10°C - + 40°C and the
ambient temperature during jump starting within
the range of – 15°C - + 40°C. Use only the sup-
plied jump start cable (Fig. 2c / Item 12).
1. Fig. 3: Pull open the cover on the jump start
cable connection (Fig. 1 / Item 7) and plug the
jump start cable into the equipment.
2. Fig. 4a: Connect the red cable to the positive
pole on the vehicle's battery and the black
cable to the negative pole on the vehicle's
battery.
3. Fig. 4a: The green „correct" LED on the jump
start cable will light up.
Note: If the green LED does not light up or
fl ashes, press the „Boost" button on the jump
start cable.
4. Start the vehicle within 30 seconds (no longer
than 5 seconds for each attempt to start the
engine, allowing at least 30 seconds waiting
time between each attempt).
5. As soon as the engine is running, remove the
jump start cable from the equipment and then
remove the red clamp from the battery fi rst,
followed by the black clamp.
6. Let the engine run. The generator will charge
up the built-in battery.
- 16 -
