NO
Part Name
1
Top cover
2
Top frame
3
Ambient temp. sensor
4
Ambient temp. sensor clip
5
Back grill
6
Isolation panel
7
Evaporator
8
Pillar
9
Motor fixture
10
Left panel
11
Motor
12
Fan blade
13
Front panel
14
Waterproof box
15
Display
16
Ventilation
17
Wiring box
18 Electric box cover
19
Transformer
20
Compressor capacitor
21
Clip
22
Motor capacitor
23
PCB
24
scaleboard
25
Electric box
26
High pressure switch
NO
Part Name
27
Exhaust pipe
28
Needle
29
Return pipe
30
Low pressure switch
31
Piping (4-way valve to exchanger)
32
Piping (4-way valve to collective pipe)
33
4-way valve
34
Compressor
35
Base tray
36
Piping (exchanger to capillary)
37
Heat exchanger
38
Drainage plug
39
Gauge
40
Terminal box
41
Clip
42
5-seat terminal
43
Terminal cover
44 Water flow switch
45
Right panel
46
Distribution pipe
47
Collective pipe
48
Blue rubber ring
49
Water connection
50
Back panel
51
Red rubber ring
- 34 -
