BY 802 S
6. Cleaning
Switch off the device and let it cool down before clean-
ing it.
Caution! Do not touch the reflector or heating element
with bare hands.
The outer surfaces of the device can be cleaned with a
damp cloth and then dried thoroughly.
No scouring agents or polishes should be used.
Dust which gathers inside the device can be removed
using a brush with soft, long bristles.
If the device is heavily soiled, it should be cleaned by a
specialist.
7. Faults
In the event of a fault, disconnect the device from the
power supply
If the heating device does not give off heat, check the
following points:
Is the display at "0"?
Is the fuse in the fuse box switched on?
If the fault cannot be corrected, please contact your
electrical retailer.
If necessary, you can also call the Glen Dimplex Ther-
mal Solutions Service Hotline.
Telephone: +49 (0) 9221 709-545
Facsimile: +49 (0) 9221 709-924545
Mail: service@gdts.one
To process your order, the device type and the device's
production date (FD number) are required. These
specifications can be found on the device's type plate.
NOTE
Repairs and corrective measures must only be carried
out by a qualified electrician or the after-sales service.
8. Spare parts
Ordering spare parts at Glen Dimplex Germany GmbH
on the Internet at:
www.dimplex.de/ersatzteile.html
9. Changing the heating element
A heating element may only be changed by a special-
ist. Disconnect the device from the power supply and
allow it to cool.
Do not touch the heating element or reflector with bare
hands. Use a cloth to protect the surface.
Loosen the front grill screws (A) and remove the
front grill.
Remove push-on connections using a suitable tool.
Pull out the two fixing brackets (B).
Remove the heating element.
Insert new heating element.
Carry out assembly in reverse order.
www.dimplex.de/en
B
A
10. Warranty
This product is supplied with a two-year warranty ac-
cording to our warranty terms and conditions.
11. Note on disposal
Do not dispose of the unit with general house-
hold waste. The unit must be taken to a local
waste disposal plant.
12. Technical data
Model reference
Nominal voltage
Degree of protection
Dimensions (W x H x D)
Weight
Heat output
Nominal heat output
Minimum heat output (indic-
ative)
Maximum continuous heat
output
Intrinsic consumption
At nominal heat output
At minimum heat output
In standby mode
Control for heat output
Two manual stages, no room temperature control
Glen Dimplex Deutschland GmbH
Am Goldenen Feld 18
D - 95326 Kulmbach
BkBs_By_EN.fm · 1709
English
BY 802 S
1/N/PE, 230 - 240 V~
IP24, splashproof
768 x 100 x 92 mm
1.9 kg
P
0.6 kW
nom
P
0.3 kW
min
P
0.6 kW
max, C
el
0.0 W
max
el
0.0 W
min
el
0.0 W
SB
Tel.: +49 9221 709 545
Fax.: +49 9221 709 924 545
Email: service@gdts.one
B
A
EN-7
