1. The appliance should never be left unattended when plugged in. 2. Always unplug this appliance from the electric outlet immediately after using and before cleaning. 3. Always unplug before re-lamping. Replace bulb with same type rated max.15W (120V), max.10W (220-240V) for model MO-735. “WARNING _____To reduce the risk of burns, fire, electric shock, or injury to persons:”...
Seite 3
1. Nigdy nie należy pozostawiać podłączonego urządzenia bez nadzoru. 2. Zawsze odłączaj urządzenie od źródła zasilania natychmiast po użyciu i przed czyszczeniem. 3. Zawsze odłączaj przed wymianą lamp. Zastąp żarówkę tym samym typem: maks. 15W (120V), maks. 10W(220-240V) dla modelu MO-735. “OSTRZEŻENIE! ________ W celu zmniejszenia ryzyka poparzeń, pożaru, porażenia prądem lub obrażeń.”...
1. Die Overlockmaschine nie unbeaufsichtigt stehen lassen, solange sie am Stromnetz angeschlossen ist. 2. Nach Gebrauch und vor einer Reinigung die Maschine immer vom Stromnetz trennen. 3. Vor einem Glühlampenwechsel immer Netzstecker herausziehen. MO-735: max. 15W (120V), max.10W (220 -240V), Glühlampen verwenden. “ACHTUNG _____Zum Schutz vor Verbrennungen, Brand, elektrischem Schlag und Verletzungen von Personen:”...
1. Ne pas laisser la surjeteuse sans surveillance tant qu’elle est raccordée au réseau. 2. Après usage et avant un nettoyage, séparer toujours la machine du réseau. 3. Retirer la fiche du réseau pour changer une ampoule. Employer des ampoules pour modèle MO-735: max. 15W (120V), max. 10W (220 - 240V).
All manuals and user guides at all-guides.com Contents / Inhoud Safety regulations ........1 Setting/Practical sewing Practical sewing-Cover stitch Contents ..........5 • Thread breakage ......23 • Securing the seam end ..... 55 Details of the machine ......7,8 •...
All manuals and user guides at all-guides.com Details of the machine / Details van de machine Details der Maschine / Détails de la machine Details of the machine Details der Maschine 1. Looper cover with built in knife guard 1. Greiferdeckel mit integrierter 2.
All manuals and user guides at all-guides.com Details of the machine /Elementy maszyny Details der Maschine / Détails de la machine A n s i c h t b e i g e ö f f n e t e m View with looper cover open Greiferdeckel 1.
If the plug does not fit fully in the polarized main socket, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper polarized main socket. Do not modify the plug in any way.(for USA, Canada only) *For MO-735 use only the foot control model YC-482(USA,CANADA), YC-483N(220-240V) Dołączanie pedału kontrolnego Podłącz pedał...
All manuals and user guides at all-guides.com Preparing the machine / Using the machine Przygotowanie i używanie maszyny Maschine bereitstellen / Inbetriebnahme Préparation de la machine / mise en service Thread stand Push the support rod firmly into the socket on the back of the machine. Raise the support rod (C) fully, turning slightly until the position catches engage.
All manuals and user guides at all-guides.com Preparing the machine / Using the machine Przygotowanie i używanie maszyny Maschine bereitstellen / Inbetriebnahme Préparation de la machine / mise en service Thread / cones / spools The anti-vibration cone should be used with the wider edge at the bottom on the spool holder pin when sewing with cones.
All manuals and user guides at all-guides.com Using the machine /Używanie maszyny Inbetriebnahme / Mise en service Power/light switch Haupt- und Lichtschalter The power/light switch is conveniently placed Der Haupt- und Lichtschalter ist übersichtlich on the handwheel side of the machine in front auf der Handradseite vor der of the socket.
All manuals and user guides at all-guides.com Using the machine /Używanie maszyny Inbetriebnahme / Mise en service Two step presser foot lifter with Zweistufen Nähfusslifterhebel mit integriertem Nähfussspitzen - Anheber. integrated front foot lift Um den Nähfuss hochzustellen, den To raise the presser foot, lift the presser foot lever on the rear of the machine, until it engages Nähfusslifterhebel nach oben bewegen, bis er ansteht (A).
All manuals and user guides at all-guides.com Using the machine /Używanie maszyny Inbetriebnahme / Mise en service Looper cover To open, press to the right with your thumb in the indent provided and tilt the cover towards you. To close push it up and press lightly to the right. The cover engages automatically.
All manuals and user guides at all-guides.com Using the machine Używanie maszyny Inbetriebnahme / Einfädeln Mise en service / enfilage Inserting the needles Needles can be inserted quickly and easily with the practical needle inserter (A). Switch the machine off ( Power switch to “O”) Disconnect machine from electricity supply.
All manuals and user guides at all-guides.com Needle and thread /Igła i nić Nadel und Faden / Aiguille et fil Needles Needles must be in perfect condition. Problems can occur if needles: A are bent. B are damaged or blunt. C have hooked points.
All manuals and user guides at all-guides.com Needle and thread /Igły i nici Nadel und Faden / Aiguille et fil Thread/decorative threads Faden, Dekorfaden Sewing and special overlock threads are manufactured in a wide vari- Näh- und Overlockfäden sind in einer Vielfalt von Stärken und Qualitäten ety of types, weights and combination of fibres.
All manuals and user guides at all-guides.com Adjustments and settings /Dostosowania i ustawienia Einstellen und Bedienen / Réglage et utilisation Stitch length Stichlänge It can be adjusted while sewing. Die Stichlänge kann stufenlos und The stitch length is infinitely variable from während des Nähens eingestellt werden.
All manuals and user guides at all-guides.com Adjustments and settings /Dostosowania i ustawienia Einstellen und Bedienen / Réglage et utilisation Differential feed There are two feed dogs one front (C) and one rear (D). The two feed dogs move indepen- dently and the distance each feed dog travels during one complete movement can be ad- justed.
All manuals and user guides at all-guides.com Adjustments and settings /Dostosowania i ustawienia Funktionen und allgemeine Bedienungshinweise Fonctions et indications générales sur mode d’emploi Adjusting the differential feed Simply turn the dial in the direction desired for fully variable adjustment while sewing. Test sew. Effect Fabric Wave-free seams (G)
All manuals and user guides at all-guides.com Adjustments and settings /Dostosowania i ustawienia Einstellen und Bedienen / Réglage et utilisation Upper looper converter Obergreiferabdeckung Use the upper looper converter to sew stitches Die Obergreiferabdeckung ermöglicht das Nähen with one looper thread, such as 2-thread roll hem, von Stichen mit einem Greiferfaden, wie zum 2-thread flatlock and overlock.
All manuals and user guides at all-guides.com Settings, practical sewing /Ustawienia, szycie w praktyce Bedienen, Praktisches Nähen / Couture pratique Nähfussdruck: Presser foot pressure Der Nähfussdruck garantiert einen optimalen The presser foot pressure is factory adjusted Stofftransport. Der Druck wurde vom to a medium setting.
All manuals and user guides at all-guides.com Settings, practical sewing /Ustawienia szycia w praktyce Bedienen, Praktisches Nähen / Couture pratique Thread breakage during sewing Sew off immediately at an angle and remove the work. Re-thread. If the lower looper thread has broken, cut off both needle threads at the needles and remove surplus thread from below.
All manuals and user guides at all-guides.com Threding preparations / tips Przygotowanie do nawlekania/wskazówki Einfädeln vorbereiten / Tips Préparer l’enfilage / conseils • Switch the machine off (power switch”O") • Maschine ausschalten, Hauptschalter auf „O“ stellen. • Support rod with thread guide must be fully raised. •...
All manuals and user guides at all-guides.com Stitch chart Stitch Stitch width Thread tension Basic settings 4-Thread overlock with 7-9 mm, Left needle (yellow) 3-5 Stitch length: 2.5 integrated safety seam right and left needles Right needle (green) 3-5 Cutting width: 3 Differential: N-2 (knits) Upper looper (blue) 3-5 0.7-N (wovens)
Seite 27
All manuals and user guides at all-guides.com Stitch Stitch width Thread tension Basic settings 2-Thread chain stitch 7-9 mm, Right needle (brown) 3-5 Stitch length: 2.5 right needles Chain looper M Differential: N-2 (knits) 3-Thread overlock (left needle) 7-9 mm, Left needle (brown) 3-5 Stitch length: 2.5 + chain stitch...
All manuals and user guides at all-guides.com Wykaz ściegów Ścieg Szerokość ściegu Naprężenie nici Podstawowe ustawienia 4-niciowy owerlokowy ze 7-9 mm, Lewa igła (żółty) 3-5 Długość ściegu: 2,5 zintegrow. szwem bezpieczeństwa prawa i lewa igła Prawa igła (zielony) 3-5 Szerokość cięcia: 3 Górna sczepiarka (niebieski) 3-5 Zróżnicowanie: Dolna sczepiarka (czerwony) 3-5...
Seite 29
All manuals and user guides at all-guides.com Steek Steekbreedte Draadspanning Basisinstellingen 2-niciowy łańcuszkowy 7-9 mm, Prawa igła (brązowy) 3-5 Długość ściegu: 2,5 prawa igła Sczepiarka łańcuchowa (M) Zróżnicowanie: N-2 (breisels) 3-niciowy owerlokowy (lewa igła) 7-9 mm, Lewa igła (brązowy) 3-5 Długość...
All manuals and user guides at all-guides.com Récapitulation des points Point Largeur de point Tension de fil Réglage de base Surjet à 4 fils avec point de 7-9 mm Aiguille de gauche (jaune) 3-5 Longueur de point: 2.5 sécurité intégré Aiguille de droite et de Aiguille de droite (vert) 3-5 Position du couteau: 3...
All manuals and user guides at all-guides.com Point Largeur de point Tension de fil Réglage de base Point double chaînette à 2 fils 7-9 mm Aiguille de droite (brun) 3-5 Longueur de point: 2.5 Aiguille de droite Différentiel: Boucleur point chaînette M N-2 (tissus à...
All manuals and user guides at all-guides.com Threading 4/3 Thread OL /Nawlekanie 4/3-niciowego owerloka Einfädeln 4/3 Faden OL / Enfilage du point de surjet à 4/3 fils 1. Upper looper thread, blue markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4/3 Thread OL /Nawlekanie 4/3- niciowego owerloka Einfädeln 4/3 Faden OL / Enfilage du point de surjet à 4/3 fils 2. Lower looper thread, red markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4/3 Thread OL /Nawlekanie 4/3-niciowego owerloka Einfädeln 4/3 Faden OL / Enfilage du point de surjet à 4/3 fils 3. Right-hand needle, green markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4/3 Thread OL /Nawlekanie 4/3-niciowego owerloka Einfädeln 4/3 Faden OL / Enfilage du point de surjet à 4/3 fils 4. Left-hand needle, yellow markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading, Chainstitch and OL /Nawlekanie, ścieg łańcuszkowy i owerlok Einfädeln, Kettenstich und OL / Enfilage, point de chaînette et surjet 1.Threading chainstitch looper (purple) Place the spool on the spool holder pin as illustrated. (1,2) Bring the thread up from the spool and lay it from the front to the back into the guide.
All manuals and user guides at all-guides.com Threading, Chainstitch and OL /Nawlekanie, ścieg łańcuszkowy i owerlok Einfädeln, Kettenstich und OL / Enfilage, point de chaînette et surjet 2. Chain-needle, brown markings (use yellow tension) Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading Chainstitch and OL /Nawlekanie, ścieg łańcuszkowy i owerlok Kettenstich einfädeln und OL / Enfilage, point de chaînette et surjet Threading, Chainstitch Kettenstich einfädeln 1. Threading chain looper (purple): see page 37 1. Kettenstich Greifer einfädeln (violett), voir page 37 2.
All manuals and user guides at all-guides.com Trial sewing, thread tension / Próbne szycie, naprężenie nici Nähprobe, Fadenspannung / Essai de couture, tension de fil Sewing test After threading make a trial run. Always use a double layer of fabric to check the stitch formation and thread tension properly.
Seite 42
All manuals and user guides at all-guides.com Thread tension /Naprężenie nici Fadenspannung / Tension de fil Check your trial run Nähprobe prüfen Chainstitch and OL Kettenstich und OL 1. Upper looper thread (blue). 1. Oberer Greiferfaden (blau). 2. Lower looper thread (red). 2.
All manuals and user guides at all-guides.com Thread tension /Naprężenie nici Fadenspannung / Tension de fil Adjusting the thread tension Turn the tension dials by only quarter or half number, then test sew again and check the result. • The loops are formed on the underside. Tighten the upper looper thread tension, (blue) or loosen the lower looper thread tension, red (A).
All manuals and user guides at all-guides.com Cover/chain stitch functions /Funkcje ściegu krytego i łańcuszkowego Cover Stich Funktionen / Fonctions du point enveloppant Cover stitch The 5 mm wide cover stitch is formed with two or three needle threads and one looper thread.
All manuals and user guides at all-guides.com Cover/chain stitch functions and general operating instructions Funkcje i ogólne instrukcje do pracy ze ściegiem krytym i łańcuszkowym. Cover Stich / Kettenstich Funktionen und allgemeine Bedienungshinweise Fonctions du point enveloppant/de chaînette et indications générales sur son utilisation Upper looper release Feststellhebel für den Obergreifer If the cover stitch and chainstitch without overlock...
All manuals and user guides at all-guides.com Cover/chain stitch functions and general operating instructions Funkcje i ogólne instrukcje do pracy ze ściegiem krytym i łańcuszkowym. Cover Stich / Kettenstich Funktionen und allgemeine Bedienungshinweise Fonctions du point enveloppant/de chaînette et indications générales sur son utilisation Knife guard / cover and chain stitch extension plate When the machine is converted to cover/chain stitch, the knife guard in the looper cover is replaced by cover stitch extension plate.
All manuals and user guides at all-guides.com Threading 4 thread cover stitch /Nawlekanie 4-niciowego ściegu krytego 4 Faden Cover Stich einfädeln / Préparation de l’enfilage du point enveloppant à 4 fils 1.Threading cover stitch looper (purple) Place the spool on the spool holder pin as illustrated. (1,2) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4 thread cover stitch /Nawlekanie 4-niciowego ściegu krytego 4 Faden Cover Stich einfädeln / Préparation de l’enfilage du point enveloppant à 4 fils 2. Cover stitch R needle (pink) markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4 thread cover stitch /Nawlekanie 4-niciowego ściegu krytego 4 Faden Cover Stich einfädeln / Préparation de l’enfilage du point enveloppant à 4 fils 3. Cover stitch C needle (pink) markings Place the spool on the spool holder pin as illustrated. (1) Bring the thread up from the spool and lay it from the back to the front into the guide.
All manuals and user guides at all-guides.com Threading 4 thread cover stitch / Inrijgen van de 4-draads coverstitch 4 Faden Cover Stich einfädeln / Préparation de l’enfilage du point enveloppant à 4 fils 4. Cover stitch L needle (pink) markings Place the spool on the spool holder pin as illustrated.
All manuals and user guides at all-guides.com Threading 3 thread cover stitch (wide) Nawlekanie 3-niciowego ściegu krytego (szerokiego) 3 Faden Cover Stich einfädeln (Breit) Enfilage pour le point enveloppant à 3 fils (large) Preparation 3 thread cover stitch (wide) Cover stitch needle R (pink) Cover stitch needle L (pink) Przygotowywanie 3-niciowego ściegu krytego (szerokiego) Igła R (prawa) do ściegu krytego (różowy)
All manuals and user guides at all-guides.com Threading 3 thread cover stitch (narrow) Nawlekanie 3-niciowego ściegu krytego (wąskiego) 3 Faden Cover Stich Einfädeln (schmal) Enfilage pour le point enveloppant à 3 fils (étroit) Preparation 3 thread cover stitch (narrow) Cover stitch needle C (pink) Cover stitch needle L or R (pink) Przygotowywanie 3-niciowego ściegu krytego (wąskiego) Igła C (środkowa) do ściegu krytego (różowy).
All manuals and user guides at all-guides.com Threading chain stitch Nawlekanie ściegu łańcuszkowego 2 Faden Kettenstich einfädeln Enfilage du point de chaînette à 2 fils Preparation chain stitch Chain stitch needle R (brown) Przygotowywanie ściegu łańcuszkowego Igła R (prawa) do ściegu łańcuszkowego (brązowy). Vorbereitung 2 Faden Kettenstich Kettenstich R Nadel (braun) Préparation de l’enfilage du point de chaînette à...
All manuals and user guides at all-guides.com Sewing test and tension adjustment /Szycie próbne i dostosowywanie naprężenia Nähprobe und Sticheinstellung / Test de couture et réglages Sewing Test Cover Stich Nähprobe und Sticheinstellung After threading make a sewing test on a double layer of fabric Nach dem Einfädeln eine Nähprobe auf doppeltem Stoff nähen, to check the stitch formation and the thread tension.
All manuals and user guides at all-guides.com Tension adjustments /Dostosowywanie naprężenia Fadenspannung anpassen / Adapter la tension Tension adjustments Cover stitch Dostosowywanie naprężenia w ściegu krytym. The right needle thread forms loops on the underside: Nić prawej igły formuje pętelki po Tighten the right needle (upper looper) ten- spodniej stronie: sion (pink, R)
All manuals and user guides at all-guides.com Practical Sewing-Cover stitch /Szycie ściegiem krytym w praktyce Cover Stich praktisches Nähen / Couture pratique avec le point enveloppant Securing the seam end, cover stitch After removing your work turn it over to the wrong side. Secure the seam by pulling the loop (1) towards the left.
All manuals and user guides at all-guides.com Practical Sewing Cover stitch /Szycie ściegiem krytym w praktyce Cover Stich praktisches Nähen / Couture pratique avec le point enveloppant Simple hem Einfacher Saum Stitch length: 3-4 Stichlänge: 3-4 Differential: N-2 (depending on fabric) Differential: N-2 (je nach Material) - Mark hem depth and fold or press.
All manuals and user guides at all-guides.com Practical Sewing Cover stitch /Szycie ściegiem krytym w praktyce Cover Stich praktisches Nähen / Couture pratique avec le point enveloppant Edges with elastic Saum mit eingenähtem Elast Stitch length: 3-4 Stichlänge: 3-4 Differential: 0.7-N Differential: 0.7-N - Sew on elastic with 4-thread overlock.
All manuals and user guides at all-guides.com Practical Sewing Cover stitch /Szycie ściegiem krytym w praktyce Cover Stich praktisches Nähen / Couture pratique avec le point enveloppant Top stitching seams /ribbing/yokes Stitch length :3-4 Differential: 0.7-N - Fold or press seam to one side. - Edge stitch (or at distance desired) from the right.
All manuals and user guides at all-guides.com Practical Sewing-Chain stitch /Szycie ściegiem łańcuszkowym w praktyce Kettenstich Praktisches Nähen / Couture pratique avec le point de chaînette Gathering with chain stitch Single layer of fabric can be gathered with chain stitch and differential feed: Differential feed: 2 Stitch length: 4 Basic tension.
Das Obermesser (bewegliches Messer) ist aus Hartmetall und muss nicht ersetzt werden. Ein Auswechseln ist nur erforderlich, wenn die Spitze der Klinge beschädigt wurde. Wenden Sie sich dazu bitte an Ihren JUKI-Händler. Untermesser auswechseln Maschine ausschalten, Hauptschalter auf „O“ stellen. Maschine durch...
All manuals and user guides at all-guides.com Maintenance /Utrzymanie Wartung / Maintenance Replacing the bulb Main switch off “O”. Disconnect machine from electricity supply. Let the bulb cool down, then unscrew the bulb and replace it with a new one. The bulbs are max.15 Watt for 120V machines and max.
All manuals and user guides at all-guides.com Trouble shooting guide Problem Page The machine does not • Looper or cloth plate cover is open. • Close the looper or the cloth plate cover. sew: • The main switch is not on. •...
All manuals and user guides at all-guides.com Przewodnik po problemach problem Przyczyna Rozwiązanie Strona Maszyna nie szyje • Pokrywa sczepiarki lub płytki materiałowej jest otwarta. • Zamknij pokrywę sczepiarki lub płytki materiałowej • Wyłacznik jest ustawiony na "O" • ZWłącz maszynę (pozycja wyłącznika "I") •...
All manuals and user guides at all-guides.com Hilfe bei Störungen Problem: ö Seite Die Maschine näht nicht: • Der Greiferdeckel oder der Stoffauflagedeckel ist • Greiferdeckel oder Stoffauflagedeckel geöffnet. schliessen. • Der Hauptschalter ist nicht eingeschaltet. • Maschine einschalten, Hauptschalter auf „l“. •...
All manuals and user guides at all-guides.com Comment éliminer soi-même les pannes Défaut: è Page La machine ne coud pas: • Le couvercle du boucleur ou celui du plateau de • Refermer le couvercle du boucleur ou celui du travail est ouvert. plateau de travail.
