L sound pressure level ..................... 86.8 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ....................... 97.8 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Cutting wooden boards (front handle)
Vibration emission value ah = 16.083 m/s²
Uncertainty K = 1.5 m/s
Cutting wooden boards (rear handle)
Vibration emission value ah = 13.588 m/s
Uncertainty K = 1.5 m/s
Cutting wooden beams (front handle)
Vibration emission value ah = 16.345 m/s
Uncertainty K = 1.5 m/s
Cutting wooden beams (rear handle)
Vibration emission value ah = 13.813 m/s
Uncertainty K = 1.5 m/s
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Anleitung_TC_AP_650_E_SPK1.indb 15 Anleitung_TC_AP_650_E_SPK1.indb 15
GB
2
2
2
2
2
2
2
- 15 -
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
5.1 Changing the saw blade (Fig. 2)
Always switch off and unplug the multi-saw before
working on the machine or changing the saw
blade.
Turn the ring (a) on the blade holder (6) as shown
in Fig. 2 until the blade (4) lets itself be slipped
into the slot of the blade holder (6).
When you now let go of the ring (a) again, the ring
(a) should return to its starting position.
If this fails to happen, try turning the ring (a) by
hand into its starting position.
Pull on the blade to check whether it sits tightly in
the holder.
5.2 Adjusting the soleplate (Fig. 3)
Warning!
Pull out the power plug.
To adjust the soleplate, press the soleplate lo-
cking button (7) on the right-hand side (looking
from the bottom) in order to unlock the soleplate
(5). Set the required distance and press the so-
leplate locking button (7) on the left-hand side
(looking from the bottom) in order to lock the sole-
plate again. Check that the soleplate is secure.
