Safety Regulations; Layout And Items Supplied; Proper Use; Technical Data - EINHELL TC-AP 650 E Originalbetriebsanleitung

Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.

1. Safety regulations

The corresponding safety information can be
found in the enclosed booklet.
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.

2. Layout and items supplied

2.1 Layout (Fig. 1+3)
1 ON/OFF switch
2 Locking knob
3 Wheel selector for selecting the blade speed
4 Saw blade
5 Soleplate
6 Blade holder
7 Locking button for soleplate
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
Anleitung_TC_AP_650_E_SPK1.indb 14 Anleitung_TC_AP_650_E_SPK1.indb 14
GB
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Universal saw
•
Saw blade (1x)
•
Original operating instructions
•
Safety instructions

3. Proper use

The multi-saw is designed for sawing wood, iron,
non-ferrous metals and plastic. It should only be
used with the appropriate saw blade.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Mains voltage: .........................230-240 V~ 50 Hz
Power: ....................................................... 650 W
Stroke rate: ...................................500-3000 min
Stroke height: ........................................... 20 mm
Cutting depth in wood: ........................... 150 mm
Cutting depth in iron: ................................ 10 mm
Maximum saw blade width: ..................... 1.4 mm
Protection class: ............................................ II/
Weight: .......................................................2.8 kg
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
- 14 -
