GB
Additional information for electric power tools
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equipment
is used and may exceed the specified value in
exceptional circumstances.
The specified vibration value can be used to compare
the equipment with other electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment's
construction and layout:
1. Lung damage if no suitable protective dust mask
is used.
2. Damage to hearing if no suitable ear protection is
used.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate are
identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 Safety guard (Fig. 1/Item 15)
The safety guard (15) protects the user from
accidentally touching the saw blade (12) and
nevertheless enables you a free view of the
cutting area.
12
12.02.2010 13:03 Uhr Seite 12
The safety guard (15) must always be fitted when
carrying out cutting work.
5.2 Changing the saw blade (Figs. 2-3/Item 12)
Important!
You can fit or replace saw blades without using
any other tools.
Pull the mains plug before you fit or replace a saw
blade.
Set the selector switch for pendulum action (8) to
position 3.
The teeth of the saw blade are very sharp!
Press the blade holder (14) and insert the saw
blade (12) into the blade holder (14) as far as the
stop (Fig. 2). The teeth on the saw blade must be
pointing forwards.
Allow the blade holder (14) to slide back to
starting position. The saw blade (12) must sit in
the guide roller (10) (Figure 3).
Check that the saw blade (12) is securely
mounted in the blade holder.
Follow the instructions above in reverse order to
remove the saw blade.
5.3 Installing the parallel stop (Figure 4/Item 11)
The parallel stop (11) enables you to saw parallel
cuts.
Undo the two locking screws (13) on the
soleplate (7).
Now slide the parallel stop (11) into the guides on
the soleplate (7). You can fit the parallel stop (11)
on either the left or right of the equipment.
The guide strip must always face downwards. Set
the required distance using the measurement
scale on the parallel stop (11) and tighten the
locking screws (13) again.
5.4 Setting the soleplate for miter cuts (Figs. 5-6)
Use the Allen key (4) to loosen the screws for the
soleplate (18) on the bottom of the adjustable
soleplate (7) (Figure 5).
Pull the soleplate (7) slightly forward. The
soleplate can now be swiveled a maximum 45° to
the left and right.
If the soleplate (7) is pushed back to the rear
again, it will only function in the locking positions
at 0°, 15°, 30° and 45°, which are marked on the
graduated scale for the soleplate (9) (Figure 6).
Move the soleplate into the required position and
refasten the screw securing the soleplate (18).
However, the soleplate (7) is also easily set to
another angle. To do so, move the soleplate (7)
forwards, set the desired angle and refasten the
screw securing the soleplate (18).
