MENU 1: ADJUSTMENT
A D J U S T M E N T
[ M A N U A L
C L O C K 1 4 0
P H A S E 5
H - P O S 0 6 0
V - P S O 0 5
1 0 2 4 x 7 6 8
V : 6 0 H z H : 4
MANUAL: Individual menu options are manually
adjusted.
AUTO: Every menu option is automatically
adjusted
Notes:
• Press the button to select AUTO.
• To choose a menu option:
• To go to MENU 2:
CLOCK
The figure below demonstrates how to adjust so that
vertical flicker noise is not emitted. (
Vertical flicker noise
PHASE
The figure below demonstrates how to adjust so that
horizontal flicker noise is not emitted. (
Note:
• Adjustments to PHASE should be made only
after CLOCK has been correctly set.
Horizontal flicker noise
H-POS (horizontal positioning) and V-POS
(vertical positioning)
To center the screen image within the boundaries of
the screen, adjust the left-right (H-POS) values and
the up-down (V-POS) values. (
Adjustment
Pattern
All manuals and user guides at all-guides.com
Adjusting the screen display
A U T O
]
8 k H z
SELECT button
MENU button
buttons)
buttons)
buttons)
Screen frame
19
MENU 2: GAIN CONTROL
BLACK LEVEL and CONTRAST are optimized
before shipment, but depending on the type of
computer being used, further adjustment may be
necessary.
G A I N C O N T RO L
M A N U A L
[
BLACK LEVEL 3 0
CONTRAST 4 0
DISPLAY COLORS 2 0K
1 0 2 4 x 7 6 8
V 6 0 : H z H : 4
MANUAL: Individual menu options are manually
adjusted.
AUTO: Every menu option is automatically
adjusted using the Auto Gain Control*
function,
Notes:
• Press the button to select AUTO.
• To choose a menu option:
• To go to MENU 3:
* Auto Gain Control function
• The Auto Gain Control adjusts contrast and black
level based on the brightest color of the image
displayed. If you are not using the Adjustment
Pattern it is necessary to have an area of 5 mm x
5 mm of white displayed, and if not adjustments
may not be possible. (In such case, [OUT OF
ADJUST] will appear and setting values remain
unchanged.)
• To perform the Auto Gain Control function, first
go to MENU 3 and set [WHITE BALANCE] to
something other than [USER]. If [USER] is set,
Auto Gain Control will be disabled.
BLACK LEVEL
Total screen brightness can be adjusted while
watching the color pattern. (
CONTRAST
While watching the color pattern, adjustments can be
made so that all graduations appear. (
DISPLAY COLORS
Maximum display colors can be set.
260K (260,000) and 16M (16.19 million)
A U T O
]
6 16 M
8 H z k
SELECT button
MENU button
buttons)
Color pattern
buttons)
