42 en | Technical data
Control output S4
Principle
Minimum over threshold
voltage in V
Minimum over threshold
voltage in V
Maximum current in mA
Power output +12 V for external devices
Output voltage
Minimum output voltage
Maximum output voltage
Maximum output current in
mA
When connecting an arming device (e.g. NBS 10 / coded
arming device)
PL 1, 2, 5, 6 and S 1 - S 4
Primary line PL 3
Primary line PL 4
Terminal resistors for primary
line PL 3 blocklock in kΩ
Terminal resistors for primary
line PL 3 or PL 4 coded arming
device in kΩ
2018.02 | 05 | F.01U.076.548
Expansion modules
12 V switching
11.88
13.13
100, refer to Output current
dependencies
+12.5 V DC ± 5%
11.88
13.13
100, refer to Output current
dependencies
See above
Blocklock or coded
Coded arming device
4.7 ±1% (armed)
4.7 II 4.7 ±1% (unarmed)
4.7 ±1% (coded arming device
invalid)
4.7 II 4.7 ±1% (coded arming
device valid)
