DRIESCHER • WEGBERG

Kapazitive Schnittstelle

Spannungsfreiheit feststellen über die kapazi-
tive Schnittstelle nach VDE 0682 Teil 415
Die Prüfung auf
Spannungsfreiheit nach HR-
System (70...90 V am Meßpunkt bei 2,5 µA) erfolgt
mit kapazitiven Spannungsanzeigegeräten an den
Meßbuchsen L1, L2, L3.
Benutzen Sie nur Prüfgeräte nach VDE
0682 Teil 415 für HR-Systeme. Beachten
Sie die Betriebsanleitung der Prüfgeräte-
hersteller und VDE 0682 Teil 415. Prüfen
Sie die Prüfgeräte vor Gebrauch auf Funk-
tion!
Schutzstöpsel entfernen
-
Spannungsanzeigegerät nach Betriebsanlei-
-
tung des Herstellers mit Meßbuchsen verbin-
den und auf Spannungsfreiheit prüfen.
Nach der Prüfung Spannungsanzeigegerät
-
von den Meßbuchsen trennen.
Schutzstöpsel auf Meßbuchsen stecken um
-
das Verschmutzen der Meßbuchsen zu ver-
hindern.
Keine Kurzschlußstecker verwenden ! Die
Schutzfunktion
begrenzenden Sollbruchstelle wird bei
Verwendung
unwirksam !
Funktionsprüfung: siehe Skizze auf Seite 11.
Wiederholungsprüfung: In festen Zeitabständen
durch o.g. Funktionsprüfung bei bekannter Be-
triebsspannung. (Letzte Wiederholungs- / Funk-
tionsprüfung siehe Aufdruck am Koppelteil).
10
der
spannungs-
von
Kurzschlußsteckern
MINEX /G.I.S.E.L.A

Capacitive Interface

Verify the isolation from supply via the capaci-
tive interface according to IEC 61243-5.
The check for isolation from supply according to the
HR-system (70...90 V at the measuring point with
2,5 µA) is performed with capacitive voltage indica-
tors on the measuring sockets L1, L2, L3.
Please only use test instruments corre-
sponding to IEC 61243-5 for HR Systems.
Observe the operating manual issued by the
manufacturer of the test instruments and
IEC 61243-5. Check the test instruments for
proper operation before usage!
Remove the protective caps.
-
Connect the voltage indicator according to the
-
operating manual of the manufacturer with the
measuring sockets and check, if the switchgear
is dead.
After the check, separate the voltage indicator
-
from the measuring sockets.
Put the protective caps onto the measuring
-
sockets to avoid the formation of dirt.
Do not use any shorting plugs! The protec-
tive function of the declared breaking point
that limits voltage becomes invalid with the
use of shorting plugs.
Functional Test: see sketch on page 11.
Repeat Test: In fixed intervals with the above-
mentioned functional test and a predetermined op-
erating voltage. (Last repeat/functional test see mar-
king on the coupling).
