router and upload the data again once the
your router, please enter the WSLink app to setup again.
- After the firmware update, If the setup informations are missing, please input the setup information again.
- Firmware update process have potential risk, which cannot guarantee 100% success. If the update fail,
just press and hold the [ + / WIND ] or [ - / BARO ] key with 10 seconds and then redo the above step to
update again.
8.2

BATTERY REPLACEMENT

When low battery indicator "
antenna icon, it indicates that the 5-in-1 wireless sensor array
battery power is low respectively. Please replace with new
batteries.

8.2.1 RE-PAIRING THE SENSOR ARRAY MANUALLY

Whenever you changed the batteries of the 5-in-1 weather sensor, re-synchronization must be
done manually.
1. Change all the batteries to new ones of the wireless sensor array.
2. Press the [ SENSOR / WI-FI ] key on the console to enter sensor synchronization mode
(as indicated by the flashing antenna ).
8.3

RESET AND FACTORY RESET

To reset the console and start again, press the [ RESET ] key once or remove the backup
battery and then unplug the adapter.
To resume factory settings and remove all data, press and hold the [ RESET ] key for 6
seconds.
8.4

WIRELESS 5-IN-1 SENSOR ARRAY MAINTENANCE

REPLACE THE WIND VANE
Unscrew and remove the wind
vane for replacement.
REPLACE THE WIND CUPS
1. Unscrew and remove the
top cap.
2. Remove the wind cup for
replacement
CLEANING THERMO-HYGRO
SENSOR
1. Remove the 2 screws at the
bottom of the radiation shield.
2. Gently pull out the shield.
3. Carefully remove any dirt or
insects on the sensor (do
not let the senssors inside
get wet).
4. Clean the shield with water to
remove any dirt or insects.
5. Install all the parts back when
they are clean and fully dried.
firmware update succeed. If the console cannot connect to
" is displayed near the
33
CLEANING THE RAIN
COLLECTOR
1. Rotate the rain collector by
turning it 30° anti-clockwise.
2. Gently remove the rain collector.
3. Clean and remove any debris
or insects.
4. Install the collector when it is
clean and fully dried.
