ENGLISH
Installing the window sealing plate
You can install the window sealing plate either vertically (Fig. 8) or horizontally (Fig. 9). Adjust
the size of the opening so that the sealing plate remains fixed in it.
The following checks must be applied to installations using flammable refrigerants:
- The charge size is in accordance with the size of the room within which the refrigerant
containing parts are installed.
- Ventilation machinery and outlets are properly operated and unobstructed.
- If an indirect cooling circuit is used, the secondary circuit must be checked for the presence
of refrigerant.
- Equipment marking remains visible and legible. Markings and symbols that are illegible
should be corrected.
- The components or refrigerant piping are installed in a location where they are not
susceptible to exposure to any substance that may corrode the refrigerant containing
components, unless the components are constructed of materials that are inherently
corrosion resistant or are adequately protected against corrosion.
4. OPERATION
The following functions can be activated from the control panel or from the remote control.
On/Off
When the device is turned on, it will beep and enter standby mode. Touch the power icon
to turn the device on and off.
Mode
Press the mode icon to switch between cooling, fan and dehumidification modes.
Sleep Mode
In cooling mode, press the increase and decrease icons to activate the Sleep mode. The
device will operate saving energy and silently.
Increase and decrease icons
Use these icons to increase or decrease temperature and time.
Temperature cannot be increased or decreased in fan or dehumidification mode.
Fan speed
Under the cooling mode, press the icon to select high or low wind speed operation.
This option is not available under the dehumidification mode.
60 FORCECLIMA 7400 SOUNDLESS TOUCH
NOTE:
Under certain conditions (defrost), it may not operate at the selected speed.
Timer
Press this icon to set the timer. When the timer symbol blinks, use the increase and
decrease icons to select the desired operating time.
The timer can be set from 1 to 24 hours, and the digits increase and decrease by 1 hour.
Drainage instructions
When the air conditioner stops operating because the water tank is full, turn it off and unplug
it from the power supply. The full tank indicator (FULL) will start blinking and the appliance will
not operate until the water inside the tank is drained.
Manual drainage. Fig. 10
1. Place a container below the water outlet behind the body.
2. Unscrew the drain cap and unplug the water plug. The water will automatically flow into
a container.
NOTE:
- Move the device carefully, so as not to spill the water in the water tank at the bottom of
the body.
- Keep the drain cap and the water plug properly.
- During drainage, the body can be tilted slightly backwards.
- If the water container cannot hold all the water, before the water container is full, stuff the
water outlet with the water plug as soon as possible to prevent water from flowing to the
floor or the carpet.
- When the water is discharged, re-tighten the water plug and tighten the drain cap.
- Restart the appliance after the plug and cap are installed, otherwise condensed water of
the appliance will flow to the floor or the carpet.
Continuous drainage. Fig. 11
- Unscrew the drain cap and unplug the water plug.
- Set the drainage pipe into the water outlet.
- Connect the drainage hose to a bucket or big container.
Protection features:
Frost protection function
In cooling and dehumidification modes, if the temperature of the evaporator outlet pipe is
too low, the appliance will automatically enter protection mode to prevent damage to the
evaporator. The appliance will restart when the temperature is restored to normal values.
ENGLISH
FORCECLIMA 7400 SOUNDLESS TOUCH 61
