4.14. Legrests

In order to make it as easy as possible to get on and off, you can flip
the footplates upwards or swing the legrests out or remove them by
lifting them upwards.
• To swing the legrest out, release the catch (Fig. 52).
51.
• In the "out position" the legrest can be completely removed.
• With electronically-adjustable legrests, you must first disconnect the
connecting cable under the seat.
• To fit the legrests, repeat the procedure in reverse order.
• Swing the legrest back to the front until you hear it clearly click into
place.

4.15. Lifting and holding points

52.
To load the electric wheelchair you should ideally use ramps due to
the weight. If you still need to lift the wheelchair, grip it by firmly-fixed
frame parts or the hold points. Do not hold it by the casing, electronic
parts and other attachments. For transportation you can secure the
electric wheelchair using the two eyelets (Fig. 53/54). The wheelchair
must not be used as a vehicle seat (see Chapter 2.2).
53.
When driving, respect other road users.
54.
102
Electric wheelchair |
Electric wheelchair |
Electric wheelchair |

5. Accessories

5.1. Rearview mirror (optional)
With the optional rearview mirror, which is fitted to the armpad, you
have better all-round visibility. You can simply push or pull it to the
required position.
5.2. Crutch holder (optional)
Put the crutch in the crutch holder and then fix it to the backrest
Never step on the crutch holder and never use it as a tipping aid.
Please note that the reflectors must not be covered.
5.3. Calf strap
A calf strap is also available for a more relaxed support of the legs.
5.4. Headrest
A height and depth adjustable headrest can also be mounted on your
Ejoy.
5.5. Number plate holder
To be able to attach a number plate to your Ejoy, there is also a number
plate holder.
