Sensor error detection ................................ Yes
Short circuit detection ................................. If 0% > 30 Ω
TC input:
Min. Max.
Type temperature temperature
B +400°C +1820°C
E -100°C +1000°C
J -100°C +1200°C
K -180°C +1372°C
L -100°C +900°C
N -180°C +1300°C
R -50°C +1760°C
S -50°C +1760°C
T -200°C +400°C
U -200°C +600°C
W3 0°C +2300°C
W5 0°C +2300°C
Cold junction compensation ....................... < ±1.0°C
External CJC with Ni100 or Pt100 .............. -40 ≤ T amb. ≤ 135°C
Sensor error detection ................................ Yes
Sensor error current:
When detecting .................................... Nom. 33 µA
Else ...................................................... 0 µA
Short circuit detection ................................. If 0% > 5 mV
Voltage input:
Measurement range .................................... -800...+800 mV
Min. span ..................................................... 2.5 mV
Input resistance ........................................... 10 MΩ
Current output:
Signal range ................................................ 4...20 mA
Min. signal range ......................................... 16 mA
Updating time .............................................. 440 ms
Fixed output signal ...................................... Between 4 and 20 mA
Output signal at EEprom error .................... ≤ 3.5 mA
Load resistance ........................................... ≤ (V
Load stability ............................................... < ±0.01% of span / 100 Ω
Sensor error detection:
Programmable ............................................. 3.5...23 mA
NAMUR NE43 Upscale ............................... 23 mA
NAMUR NE43 Downscale ........................... 3.5 mA
22
Min.
span Norm
100°C IEC584
50°C IEC584
50°C IEC584
50°C IEC584
50°C DIN 43710
50°C IEC584
100°C IEC584
100°C IEC584
50°C IEC584
50°C DIN 43710
100°C ASTM E988-90
100°C ASTM E988-90
(660 ms for diff.)
- 8) / 0.023 [Ω ]
supply
Ex / I.S. data:
Signal output / supply, terminal 1 to 2:
U i ................................................................. : 30 VDC
I i .................................................................. : 120 mADC
P i ................................................................. : 0.84 W
L i ................................................................. : 10 µH
C i ................................................................. : 1.0 nF
Sensor input, terminal 3, 4, 5 and 6:
U o ............................................................... : 9.6 VDC
I o ................................................................. : 28 mA
P o ................................................................ : 67 mW
L o ................................................................ : 35 mH
C o ................................................................ : 3.5 µF
Ex / I.S. appoval 5335A:
Kema 03ATEX1508 X ..................................
Ex / I.S. approval 5335B, C and D:
KEMA 03ATEX1537 X ..................................
Max. amb. temperature for T1...T4 ............. 85°C
Max. amb. temperature for T5 and T6 ....... 60°C
ATEX, applicable in zone ............................ 0, 1, 2, 20, 21 or 22
FM, applicable in ......................................... IS, Class I, DIV. 1, Group A, B, C, D
Entity, FM Installation Drawing No. ............. 5300Q502
CSA, applicable in ....................................... IS, Class I, DIV. 1, Group A, B, C, D,
Installation Drawing No. .............................. 533XQC03
Marine approval:
Det Norske Veritas, Ships & Offshore ......... Standard for Certification No. 2.4
Observed authority requirements:
EMC 2004/108/EC
Emission and immunity ....................... EN 61326
ATEX 94/9/EC .............................................. EN 50014, EN 50020, 50284
FM, ASCN ................................................... 3600, 3611, 3610
CSA, CAN / CSA ......................................... C22.2 No. 157, E60079-11, UL 913
Of span = Of the presently selected range
II 3 GD
EEx nA[L] IIC T4...T6
II 1 GD, T80°C...T105°C
EEx ia IIC T6 / T4
IS, Class I, Zone 0, AEx ia IIC
Ex ia IIC
IS, Class I, Zone 0, AEx ia IIC
Standard:
EN 50021 and EN 50281-1-1
