Step by step:
1. Make sure that there is no power in the trailer by disconnecting the trailer from the car.
Connect the 12V trailer power cable to an existing power source inside the trailer. Connect
the horse shoe joint of the white-striped cable to the positive pole (+) and the horse shoe joint
of the all black cable to the negative pole (-) of the power source.
2. Attach the black camera antenna (2dBi) to the camera.
3. Make sure that there is power running through the 12V trailer power cable by connecting the
car to the trailer. Start the car and ensure that the red LED on the adaptor box is illuminated.
4. Connect the other end of the cable to the camera.
5. Hold the camera in a suitable location inside the trailer, maximum 1,5 meters from an existing
power source.
6. Bring the LCD-monitor to the car cabin to make sure you receive a satisfying picture quality
and that the chosen position allows you to see your horse in a satisfying way.
7. Attach the extra mounting foot on the chosen position using the included screw or bolts and
nuts. Attach the camera on to the mounting foot.
8. Place the LCD-monitor holder in the front window of your car, the dashboard or in the air con
outflow. Make sure that the holder does not block the driver's field of vision.
9. Connect the 5V cigarette adaptor to the car cigarette lighter socket. Connect the other end of
the cigarette adaptor to the LCD-monitor socket marked with DC 5V IN to constantly supply
the monitor with power and to charge the battery.
If questions or problems rise during the installation, read chapter 16 through,
"Troubleshooting the supervision inside your trailer".
