Operating Elements - Soehnle Shape Sense Control 200 Bedienungsanleitung

A. Operating elements
GB
1. Minus ( )
2. Confirm ( )
3. Plus ( )
Sensor Touch:
Touch keys only slightly!
B. Preparation
1. Remove battery strip.
Note: Immediately (as long as „0.0" is still
being displayed) place the body analysis scale
on a level surface and wait until the scale pow-
ers down automatically.
Then begin data input. Otherwise, it might be
possible that the weight of the scale would erro-
neously be added to the initial weighting pro-
cess.
The same might occur during regular operation
if the scale is held in the hand prior to the
weighting process.
2. For all measurements, place scale level on a
hard surface (not carpet).
3. Cleaning and Care: clean only using slightly
damp cloth. Do not use solvents or abrasives.
Never submerge scale in water.
4. A country-specific option to switch from kg/cm
to lb/in or st/in is possible by pushing the key
on the bottom of the scale to switch units.
Attention! Slipping hazard
in case of wet surface.
C. Data input
1. Push key.
2. Use / keys to select memory slot and con-
firm ( ).
3. Then use / keys enter body height and con-
firm.
Note: For unit conversion, see section B.4.
4. In the next step enter the age and confirm.
5. Finally select sex and confirm (Press
sec.).
6. Now immediately place the body analysis scale
on the floor, wait until the screen displays „0.0"
4
and then step on the scale with bare feet.
The initial measurement is indispensable and
serves to store the data for later automatic reco-
gnition of persons. If no person steps on the
scale, data input must be repeated.
The first body analysis is performed after a per-
son steps on the scale.
This scale is equipped with a Time-Out mode.
It will automatically switch off after approx. 40
seconds if no keys are pressed.
Data must be entered again after battery
change.
D. Body analysis
1. Place scale on hard, level surface and wait until
the scale switches off automatically.
2. Step barefoot onto scale. Please stand still.
3. The body weight will be displayed.
The scale determines the body values (body fat,
body water, muscle mass, kcal).
Note: Body values are calculated based on the
determined weight and the personal data.
The scale shuts off auto matically.
E. Notifications
1. Replace batteries
2. Overload: max. 180 kg
3. The measured value is higher (H) or lower (L)
than the limit.
L
< 10 % > 60 % < 5 % > 90 % < 5 % > 90 %
< 4 % > 60 % < 5 % > 90 % < 5 % > 90 %
F. Technical data
Max. 180 kg / 100 g
Max. 396 lb / 0.2 lb
Max. 28 st / 0.2 lb
Age: 17-99 years
Batteriy requirement: 1 x 3V CR 2430
key 3
H L H L H
