4.1.3 Alternative pin configurations
The outputs of REX receivers can be set to various functions.
Outputs marked as E1, E2 ...:
Servo - classic servo output (except E1 output for REX10)
JETIBOX/Sensor - for connecting JETIBOX or telemetry sensor
with EX communication
EX Bus - digital communication for connected devices supporting
this standard, for example M Vario2 (rev.2).
EX Bus input/backup - EX Bus communication for connecting
others receivers and satellite receivers.
Digital output -the output pin is in a stable LOW condition (log. 0) if
the position of this channel is negative, otherwise this pin is in
HIGH condition (log.1) (max. current 1mA).
Digitl input - the logical value (log.1/0) at the input can be used in
further programming of transmitter functions.
PPM pos. - standard form of PPM signal generation with positive
logic at PPM outputs. The bus idle state is log. 0.
PPM neg.- standard form of PPM signal generation with negative
logic at PPM outputs. The bus idle state is log.1.
Serial UDI 12ch/16ch - serial output for devices supporting UDI
(Universal Data Interface)
S.BUS - serial output for devices supporting S.BUS
Outputs marked as Ext.: connection of JETIBOX or telemetry
sensors (EX or EX Bus), the output has automatic detection.
Standard outputs:
Servo - standard impulse output for servos (-100% = 1ms, 0%=
1,5ms / +100% = 2ms )
Digital input/output - see description of E1, E2
