3.2 Binding

When using a new receiver or transmitter, the device has to be
bound.
Method:
1. Insert the BIND PLUG (included in the package) into the output
of the receiver Ext.
2. Switch on the receiver – (connect a proper voltage supply to the
receiver). Binding of the receiver may now be performed within 60
seconds. After the 60 seconds elapse the receiver returns to setup
mode and the binding process has to be repeated by starting again
from step 1.
3. Switch on the transmitter - the transmitter emits an acoustic
signal announcing the detection of a new receiver.
4. Disconnect the BIND PLUG from the receiver
Note: if binding fails, turn off the transmitter and receiver and
repeat all the procedures from point 1.
If the binding was successful, the transmitter, receiver and the
specific model that was currently active in the transmitter are
bound to the same group.

3.3 Operation of receivers in "Clone" mode

The Duplex system allows many of receivers to be bound with one
model. Always one receiver that transmits telemetry data has to be
in "Normal" mode. All others can be manually switched to "Clone"
mode.
