Anschluss An Lsg-Steam/Emotouch 3 - EOS SteamRock II Basic Montage- Und Gebrauchsanweisungen

6.5 SteamRock II Basic Anschlussplan an LSG Steam (EmoTouch 3)
SteamRock Basic / SteamRock II Basic
9,0 kW
L1 L2 L3 N N N N PE PE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
L1 L2 L3 N PE
400 V 3N ~ 50 Hz 16 A + PE
SteamRock Basic / SteamRock II Basic
18,0 kW
L1 L1 L2 L2 L3 L3 N N N N N N N N PE PE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
L1 L2 L3 N PE
400 V 3N ~ 50 Hz 32 A + PE
Temperaturfühler / Temperature sensor
N A2 PE
N S1 Wb PE
18 19 20 21
Temperaturfühler / Temperature sensor
N A2 PE
N S1 Wb PE
25 26 27 28
D
EmoTouch 3 (LSG Steam)
Leistungsteil
Main unit (relay box)
Relais box
L1 L2 L3 N W V U N
S1 S1 N
PE
EmoTouch 3 (LSG Steam)
Leistungsteil
Main unit (relay box)
Relais box
L1 L2 L3 N W V U N
S1 S1 N
PE
reserviert
Sensorbus
Saunabus
Bedienteil
WB N WM
3 4
F L FN LL LN
STB
PE
N
L
230 V AC
Steuerung
Control
reserviert
Sensorbus
Saunabus
Bedienteil
WB N WM
3 4
F L FN LL LN
STB
PE
N
L
230 V AC
Steuerung
Control
Display
Display
33
