˜ Parts description
Figure A:
Impact force control
1 ]
[
Battery level indicator
2 ]
[
Trigger
[
3 ]
Battery latch
[
4 ]
Battery pack *
[
5 ]
Belt clip
[
6 ]
Release button
[
7 ]
Magazine
8 ]
[
Push rod
9 ]
[
Fill indicator (staples)
[
]
Safety contact
[
]
Fill indicator (staples and nails)
[
]
Figure E:
Rib
[
]
Hook
[
]
Figure H:
Charger *
[
]
Charge status indication light – green
[
]
Charge status indication light – red
[
]
Power cord with power plug
[
]
Not illustrated:
Carrying case
[
]
* Battery pack and charger are not included
10 GB
˜ Technical data
Cordless stapler/nailer:
Model number
Rated voltage
Max. impact rate
Magazine capacity
Wire staples
Staple crown width
(outside)
Staple length
Nails
Nail width
Nail length
Battery packs *
Model number
Type
Rated voltage
Capacity
Number of cells
Model number
Type
Rated voltage
Capacity
Number of cells
: PAT 12 B2
: 12 V
: 140 min
–1
: 100 staples
or
50 nails
: 11.7 mm
: 6–14 mm
Type 53 / JT21
6–14 mm
: 1.2 mm
: 14–15 mm
Type 47 /
18-Gauge
14–15 mm
: PAPK 12 A3
: Lithium ion
: 12 V
: 2000 mAh
: 3
: PAPK 12 B3
: Lithium ion
: 12 V
: 4000 mAh
: 6
