Dust Blower (Fig. G)
The dust blower
 13
helps clear the cutting area of debris
created from the blade.
Dust Extraction (Fig. A, H)

WARNING: Dust can be hazardous to health. Always
work with a dust extractor. Always observe the national
regulations for work with dust emitting tools.
The dust extraction chute in combination with the dust
extraction shroud helps extract dust from the workpiece surface,
when connected to a suitable dust extraction system.
nOTE: The tool will not bevel if the dust extraction accessories
are attached to the tool.
1. Place the dust extraction shroud
guard
 5
(Fig. A) until it clicks into place.
2. Slide the dust chute
 15
it snaps into the dust shroud. Be sure the adapter end is
facing up.
3. To connect a vacuum to the dust chute
AirLock (DWV9000), found on all full size D
hoses, over the dust collection port, and twist the collar
to lock it into place. The dust chute will also fit a standard
35 mm connector.
Removeable Anti-Scratch Shoe Cover (Fig. I)
The anti‑scratch shoe cover
surfaces that scratch easily, such as laminate, veneer or paint.
To attach anti‑scratch shoe cover
shoe
 7
into the front of the anti‑scratch shoe cover and lower
the jig saw. The anti‑scratch shoe cover will click securely onto
the rear of the shoe.
To remove anti‑scratch shoe cover, grasp the anti‑scratch shoe
cover from the bottom; holding onto the two rear tabs
remove the anti‑scratch shoe cover.
Anti-Splinter Insert (Fig. I, J)
nOTE: Do not use the anti‑splinter insert with the flush
cutting blade DT74.
The anti‑splinter insert
 10
minimize tear‑out, especially when cutting veneer, laminate, or
finished surfaces, such as paint. The anti‑splinter insert should
be installed into the anti‑scratch shoe cover
cover is not used, install anti‑splinter insert into shoe
Setting the Electronic Sawing Speed
(Fig. A, K)
DCS334
To preset the sawing speed, turn the speed control dial
desired level. The higher the number on the speed control dial,
the higher the sawing speed. The sawing speed varies with the
pressure exerted on the variable speed trigger
exceed the speed that is set by the speed control dial
required setting depends on the thickness and kind of material.
nOTE: Use high speeds for sawing soft materials such as wood.
 14
onto the finger
from the back of the tool until
 15
, place a D
WALT vacuum
e
 16
should be used when cutting
 16
, place the front of the
should be used when trying to
 16
. If the no‑mar
 7
 1
, but will not
 3
DCS335
The speed control dial
required range of speed.
1. Turn the electronic control dial to the required level. The
DCS335 will turn on at that speed when the on/off switch is
moved to the ON position. The required setting depends on
the thickness and kind of material.
nOTE: Use high speeds for sawing soft materials such as wood.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can cause injury.
WALT
e

WARNING: Always wear proper personal hearing
protection. Under some conditions and duration of use,
noise from this product may contribute to hearing loss.

WARNING:
Make sure your workpiece is well secured. Remove
nails, screws and other fasteners that may damage
the blade.
Check that there is sufficient space for the blade
underneath the workpiece. Do not cut materials that
are thicker than the maximum cutting depth.
Use sharp saw blades only. Damaged or bent saw
blades must be removed immediately.
Never run your tool without a saw blade.
 17
For optimal results, move the tool smoothly and
constantly over the workpiece. Do not exert lateral
pressure on the saw blade. Keep the shoe flat on the
workpiece. When sawing curves, circles or other round
shapes, push the tool gently forward.
Wait until the tool has come to a standstill before
removing the saw blade from the workpiece. After
sawing the blade may be very hot. Do not touch.
Proper Hand Position (Fig. E)
.

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
 3
to the
Proper hand position requires one hand on the
main  handle
Lock-Off Button and Variable Speed Trigger
. The
(Fig. A)
DCS334
To lock the variable speed trigger
 3
can be used for advance setting of the
 10
. Keep other hand clear of cutter area.
 1
, press the lock‑off
EngliSh
13
