Belt Hook and Magnetic Bit Holder (Fig. A)

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool's belt hook
from a work belt.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook is secure.
iMPORTAnT: When attaching or replacing the belt hook or
magnetic bit holder, use only the screw
sure to securely tighten the screw.
The belt hook 8 and magnetic bit holder
to either side of the tool using only the screw
to accommodate left- or right- handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
the tool.
To move belt hook or magnetic bit holder, remove the screw
that holds it in place then reassemble on the opposite side. Be
sure to securely tighten the screw.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Proper Hand Position (Fig. C)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main
handle 10 .
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
tool off, release the trigger switch. Your tool is equipped with a
brake. The tool will stop when the trigger switch is fully released.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes or fasteners.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
10
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
the tool and also serves as a lock-off button.
To select forward rotation, release the trigger switch
depress the forward/reverse control button
of the tool.
To select reverse, release the trigger switch
the forward/reverse control button
tool. The centre position of the control button locks the trigger
switch in the off position. When changing the position of the
control button, be sure the trigger is released.
nOTE: The first time the tool is run after changing the direction
that is provided. Be of rotation, you may hear a click on start up. This is normal and
9
does not indicate a problem.
12 can be attached
Worklights (Fig. A)
9 provided,
There are three worklights
chuck
is depressed.
When the trigger is released, the worklight will stay illuminated
9
for up to 20 seconds.
nOTE: The worklights are for lighting the immediate work
surface and are not intended to be used as a flashlight.
Mode Selector (Fig. A, D)
Your tool is equipped with a mode selector
you to select one of three modes. Select the mode based on the
application and control the speed of the tool using the variable
speed trigger switch
Precision Drive (Fig. D)
In addition to normal impacting modes, this tool features the
Precision Drive mode which enables greater control in lighter
applications to avoid damage to materials or fasteners. It is ideal
for light applications such as cabinet hinge screws or machine
screws. Precision Drive mode will work as a screwdriver in light
applications, before hesitating as the screw head reaches the
work piece, and then (if required) start a slow controlled impact
to ensure the head ends perfectly flush.
nOTE: This mode is for light duty screwdriving applications. If
the tool will not drive a fastener in Precision Mode, please select
mode 2 which will give the additional power required.
Mode 1
1 . To turn the
Mode 2
Mode 3
Quick-Release Chuck (Fig. B, E, F)

nOTE: The chuck accepts 6.35 mm hex accessories only.
Place the forward/reverse button
position or remove battery pack before changing accessories.
determines the direction of
2
2
located around the 6.35 mm hex
7
4 . The worklights are activated when the trigger switch
1 .
DCF887
Precision Drive
Normal Impacting
High Speed Impacting
WARNING: Use only impact accessories. Non-impact
accessories may break and cause a hazardous condition.
Inspect accessory prior to use to ensure that it con tains
no cracks.
2 in the lock-off (centre)
1 and
on the right side
2
1 and depress
on the left side of the
11 which allows
rpm 0–1000
rpm 0–2800
rpm 0–3250
