REMOVING THE COVER OF THE DOOR
1. Push the pins (A) on each side of the door.
2. Remove the cover (B).
Note:
When the cover is removed, the glass panels inside the door are also accessible.
3. After cleaning, install the cover again. Refer to section
INSTALLING THE COVER OF THE DOOR
Caution:
Make sure that the glass panels are installed correctly.
1. Carefully push the cover (A) in the door until you hear a click.

REPLACING THE LAMP

Warning:
Make sure that the appliance is cooled down.
Preliminary requirements
1. The appliance is switched off.
2. The appliance is disconnected from
the mains supply.
Procedure
1. Turn the glass cover (A) counter-clockwise to remove it.
2. Carefully pull the lamp (B) to remove it.
3. Replace the lamp.
4. Install the glass cover.
Closing requirements
1. Connect the appliance.
REPLACING THE SIDE LAMP
Warning:
Make sure that the appliance is cooled down.
Preliminary requirements
1. The appliance is switched off.
2. The appliance is disconnected from
the mains supply.
Procedure
1. Open the cover (A).
2. Carefully pull the lamp (B) to remove it.
'Installing the cover of the door'
• Halogen lamp (25W, 230V, T300°C)
• Halogen lamp (25W, 230V, T300°C)
(Figure 13)
.
(Figure 14)
(Figure 15)
(Figure 16)
English • 39
