1. INTRODUZIONE Il presente manuale descrive l’installazione delle centrali MP3040 e MP3100. Le centrali MP3000 sono sistemi ibridi che integrano connessioni filari e radio, consentono l’utilizzo di sensori con video verifica degli allarmi e presentano funzioni di Home Automation. Le centrali sono dotate di connessione alla rete LAN, permettendo in questo modo la gestione e l’utilizzo da remoto.
Seite 5
CARATTERISTICHE TECNICHE Tensione nominale di alimentazione 220-240 V~ +10% -15% 50/60 Hz Tensione nominale di uscita 14,4 V⎓ Corrente massima assorbita a 230 V 0,6 A Alimentatore Corrente massima erogabile 1,5 A PS515 Ripple max 100 mVpp con I=1A Fusibile T2AL 250 V~ Classe di isolamento (1) Se la batteria non è...
DESCRIZIONE SCHEDA CPU LEGENDA LAY-OUT SCHEDA CPU Acceso=funzionamento normale LED ROSSO Lampeggiante=comunicazione bus OPER LED VERDE Lampeggiante=avvio sistema Positivo alimentazione (13,8 V⎓) LED VERDE Lampeggiante= funzion. normale A / B BUS trasmissione/ricezione dati A / B Negativo alimentazione (GND) +3V3 LED ROSSO Alim.
3.1 COLLEGAMENTO BUS CENTRALE Collegare ai morsetti +, A, B, – il cavo a 4 fili del BUS che metterà in comunicazione centrale, lettori, tastiere ed espansioni. È inoltre presente un connettore BUS polarizzato per il collegamento dell’interfaccia espansione radio ER3000-RF tramite cavo in dotazione all’interfaccia, quando questa è...
Elkron Connect, scaricabile gratuitamente tramite Play Store per la versione Android o App Store per la versione iOS. Per utilizzare l’accesso remoto è necessario che l’installatore sia registrato sul sito Elkron con accesso ai servizi cloud e che abbia effettuato l’associazione della centrale tramite l’UID presente sull’etichetta della scheda CPU.
1. INTRODUCTION This manual describes the installation of MP3040 and MP3100 control panels. MP3000 control panels are hybrid systems that integrate wired and wireless connections using sen- sors with video verification of alarms and home automation functions. The control panels are equipped with a LAN connection, thus allowing remote management and operation.
Seite 10
TECHNICAL FEATURES Nominal power voltage 220-240 V~ +10% -15% 50/60 Hz Nominal output voltage 14,4 V⎓ Rated current consumption at 230 V 0,6 A PS515 Max. current that can be delivered 1,5 A power unit Max. ripple 100 mVpp con I=1A Fuse T2AL 250 V~ Insulation class...
CPU BOARD DESCRIPTION CPU BOARD LAYOUT KEY On = Normal operation RED LED Flashing = Bus communication OPER GREEN LED Flashing = System start Power positive (13,8 V⎓) GREEN LED Flashing = Normal operation A / B BUS Data transmission/reception A / B Power negative (GND) +3V3 RED LED...
3.1 CENTRAL BUS CONNECTION Connect the 4-wire BUS cable for connecting control panel, readers, keypads and expansion modules to the +, A, B, – terminals. A polarised BUS connector is also present for connecting the ER3000-RF wireless expansion interface using the cable supplied with the interface, when it is installed inside a box. Use a 4-core shielded multipolar cable with a cross-section area suited for the current drawn by the connected devices to connect the BUS.
4. CONFIGURING THE CONTROL PANEL Off the shelf, MP3040 and MP3100 control panels have a default configuration compatible with EN50131 certification grade 2. Two different programming modes are provided on the integrated web server, namely a STANDARD mode, allowing action on every single system parameter with the MP Control configurator, and an EASY mode, to put the system into service with a typical configuration with the help of the eMPi virtual assi- stant in a few simple steps.
1. INTRODUCTION Le présent Manuel illustre l’installation des centrales MP3040 et MP3100. Les centrales MP3000 sont des systèmes hybrides, qui intègrent des connexions filaires et radio. Elles permettent d’utiliser des capteurs avec vérification vidéo des alarmes et elles comportent des fonctions de Domotique.
CARACTERISTIQUES TECHNIQUES Tension nominale d’alimentation 220-240 V~ +10% -15% 50/60 Hz Tension nominale de sortie 14,4 V⎓ Courant nominal absorbé à 230 V 0,6 A Alimentateur Courant maximum fourni 1,5 A PS515 Ondulation maximale 100 mVpp con I=1A Fusible T2AL 250 V~ Classe d’isolation (1) Si la batterie n’est pas branchée, il n’y aura pas de tension aux cosses des câbles de connexion (connecteurs Faston rouge et noir).
Seite 16
DESCRIPTION DE LA CARTE CPU LÉGENDE DU SCHÉMA D’IMPLANTATION DE LA CARTE CPU Allumée = fonctionnement normal LED ROUGE Clignotante=communication bus OPER LED VERTE Clignotante = démarrage système Positif alimentation (13,8 V⎓) Clignotante = fonctionnement LED VERTE normal A / B BUS de transmission/réception de données A / B Négatif alimentation (GND) +3V3...
3.1 CONNEXION DU BUS DE LA CENTRALE Brancher sur les bornes +, A, B et - le câble à 4 fils du BUS qui mettra en communication la centrale, les lecteurs, les claviers et les expansions. Il existe également un connecteur BUS polarisé pour la connexion de l’interface d’expansion radio ER3000-RF à...
Seite 18
Elkron Connect, à télécharger gratuitement sur Play Store (version Android) ou App Store (version iOS). Pour utiliser l’accès à distance, l’installateur doit être inscrit sur le site Elkron avec accès aux services Cloud et il doit avoir effectué l’appariement de la centrale en utilisant l’UID qui figure sur l’étiquette de la carte CPU.
1. EINLEITUNG Dieses Handbuch beschreibt die Installation der Zentralen MP3040 und MP3100. Die Zentralen MP3000 sind Hybridsysteme, die verdrahtete und Funkverbindungen integrieren, gestat- ten den Einsatz von Sensoren mit Videoüberprüfung der Alarme und sind mit Funktionen der Home Automation ausgestattet. Die Zentralen sind für die Verbindung mit dem LAN ausgelegt und gestatten so die standortferne Verwaltung und Bedienung.
TECHNISCHE EIGENSCHAFTEN Nennversorgungsspannung 220-240 V~ +10% -15% 50/60 Hz Nennausgangsspannung 14,4 V⎓ Nennstromaufnahme bei 230 V 0,6 A Netzgerät Max. Stromleistung 1,5 A PS515 Max. Ripple 100 mVpp con I=1A Schmelzsicherung T2AL 250 V~ Schutzgrad (1) Ist die Batterie nicht an die Anschlüsse der Verbindungskabel angeschlossen (roter und schwarzer Flachstecker), liegt keine Spannung an.
3.1 BUS-ANSCHLUSS ZENTRALE An die Anschlussstifte +, A, B und - vier Adern des BUS-Kabels anschließen, das Zentrale, Lesegeräte, Tastenfelder und Erweiterungen miteinander verbindet. Außerdem ist ein polarisierter BUS-Verbinder für den Anschluss der Schnittstelle der Funkerweiterung ER3000-RF mit dem im Lieferumfang enthaltenen Kabel vorhanden, wenn diese im Inneren des Kun- ststoffgehäuses installiert ist..
Fernzugriff über das Portal Elkron Cloud (https://www.cloud.elkron.com/webinstaller) oder die App Elkron Connect, die kostenlos über Play Store für die Version Android oder App Store für die Ver- sion iOS heruntergeladen werden kann. Zur Verwendung des Fernzugriffs muss der Techniker auf der Website Elkron mit Zugriff auf die Cloud-Dienste registriert sein und muss die Zuordnung der Zentrale mittels UID auf dem Etikett der CPU-Platine vorgenommen haben.
